Wiremold® RC4ATCBK Multi-Service Assembled Poke-Through Device, 4 in Hole, 24.5 cu-in, Steel Stem
Poke-Through Assembled Units
102295
MFG #: RC4ATCBK
Wiremold®
486.48000
/ ea
The RC4 Series poke-thru device delivers significant power and communication services directly to the workstation. It is supplied with two prewired 20A duplex receptacles that can be wired in the field as a standard or isolated ground receptacle. The RC4 Series also accepts up to four ports of connectivity devices to provide a seamless and aesthetically pleasing interface for voice, data and fiber optic applications at the point of use.
- Brochure URL - 1CB3D275DE654450B03A46C6342470A0.pdf(Brochure URL)
- http://www.wiremold.com(WEB SELLER HOME PAGE URL)
- IDW Material Composition - ROH_Legrand_ROHS_statement.pdf(IDW Material Composition)
- WEB CATALOG URL - IDW_DOCUMENT_cef5ab214764940bc547335c72e3f452b86e47825aa179ba59a9d1da407d29ca.pdf(WEB CATALOG URL)
- WEB DATA SHEET 1 URL - Legrand_AV3ATCBK_Data_Sheet.pdf(WEB DATA SHEET 1 URL)
- WEB INSTALL INSTR URL - 7F585C9B7AA6428185F8612E49B34B9F.pdf(WEB INSTALL INSTR URL)
- WEB ROHS COMPLIANCE URL(WEB ROHS COMPLIANCE URL)
- WEB SPEC SHEET URL - 1CB3D275DE654450B03A46C6342470A0.pdf(WEB SPEC SHEET URL)
- WEB TECH DRAWING URL - FA2284B356B0442A91554F329B738BA2.dxf(WEB TECH DRAWING URL)
- WEB WARRANTY URL - Wiremold_Warranty.pdf(WEB WARRANTY URL)
- Features
| 2 duplex receptacles, 4 ports for communications, slide doors, step on it installation, low profile cover |
| Each duplex receptacle is wired as separate circuit |
| The duplex can be wired as a standard receptacle or isolated ground |
| Not designed to work with bare concrete or terrazzo floors |
| Floor covering thickness 1/8 in minimum |
| 2-duplex receptacles |
| Knockout cable entry |
| Step on mounting, retaining clips |
| 4-port for communications |
| Assembled with scrub water gasket |
| For use on tile or carpet floors |
| RC4 series poke-thru devices require a 4 in Dia hole |
| Slide doors, step on it installation, low profile cover |
