Turck multifast® DSM DKM 28-061-20 Double Ended Cordset, M27 x 1 Straight Male x Straight Female Connector, 20 m L Cable
Quick Connect Cable Assemblies
PDW~12217539
MFG #: U-24408
Turck
0.00000
/ ea
Turck multifast® Cordset, Double Ended, Straight Male x Straight Female Connector, M27 x 1 Connector, Brass, Shielded Cable, 20 m Cable Length, PVC Cable, 28 Pole, 150 VAC, 5 A, Brown/White/Gray/Blue/Gray/Brown/Gray/Black/Yellow/White/Yellow/Blue/Yellow/Brown/Yellow/Black/Red/White/Red/Blue/Red/Brown/Red/Black/White/Blue/Black/Gray/Brown/Orange/White/Orange/Black/Orange/Black/Green/White/Green/Blue/Green/Brown/Green/Blue/Orange/Green/Yellow/Gray/Orange Wire Pin Colors, IP67 IEC Rating
- Features
| 27 conductors |
| 22 AWG yellow cable |
| Nylon or PBT contact carriers |
| Black TPU molded head material |
| Gold plated brass contact material |
| Nickel plated brass coupling nut |
| Yellow PVC outer jacket material |
| PVC conductor insulation material |
| -40 to 105 deg C operating |
| 22 AWG drain/aluminum-polyester foil shield |
