Turck minifast® RSM RKM 5711-15M Double Ended Cordset, 7/8-16 UN Straight Male x Straight Female Connector, 15 m L Cable
Quick Connect Cable Assemblies
482778
MFG #: U5452-68
Turck
171.42000
/ ea
Turck minifast® Cordset, Double Ended, Straight Male x Straight Female Connector, 7/8-16 UN Connector, Brass, 15 m Cable Length, PVC Cable, 5 Pole, 300 VAC, 7 A, Bare/Red/Black/White/Blue Wire Pin Colors, NEMA 1/3/4/6P/IP67
- Features
| Gray cable jacket color |
| Nickel plated Brass coupling nut |
| Gold plated brass contact material |
| 2 x 16 AWG, 2 x 20 AWG color code, 20 AWG drain |
| TPU contact carrier, blue/gray contact molded head |
| -40 to 80 deg C operating temperature |
| DeviceNet™ fieldbus protocol |
| 5 conductors |
| Polyethylene data, PVC power |
