Square D™ QO230SWN1021 Type QO-SWN Miniature Circuit Breaker, 120/240 VAC, 48 VDC, 30 A, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, 2 Poles, Shunt/Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ QO230SWN1021 Type QO-SWN Miniature Circuit Breaker, 120/240 VAC, 48 VDC, 30 A, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, 2 Poles, Shunt/Thermal Magnetic Trip
SKUPDW~6415141
MFGR #QO230SWN1021
Your Cost: $257.82/ea
List: Square D™ Miniature Circuit Breaker, Type QO-SWN, 120/240 VAC, 48 VDC, 30 A, 50/60 Hz Frequency, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, Shunt/Thermal Magnetic Trip, 2 Pole, 1 ph, Pressure Plate Connection, 14 to 8 AWG Al/Cu Wire, NEMA AB1 Enclosure, Plug-In Mounting, 104 deg F, 3 in H x 2.25 in W x 2.91 in D Dimensions, Fiberglass Filled Thermoset
Square D™ Miniature Circuit Breaker, Type QO-SWN, 120/240 VAC, 48 VDC, 30 A, 50/60 Hz Frequency, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, Shunt/Thermal Magnetic Trip, 2 Pole, 1 ph, Pressure Plate Connection, 14 to 8 AWG Al/Cu Wire, NEMA AB1 Enclosure, Plug-In Mounting, 104 deg F, 3 in H x 2.25 in W x 2.91 in D Dimensions, Fiberglass Filled Thermoset
Alternate Catalog Number QO230SWN1021 Application Residential and Light Commercial, Commercial and Industrial Circuit Protection, Overcurrent Protection, Short Circuit Protection, Parallel and Series Arc Fault Protection and Ground Fault Protection Applications ARRA Compliant N Buy American Compliant N Catalog Number QO230SWN1021 Connection PRESSURE PLATE #14 TO #8 AWG(AL/CU) Country of Origin MX Currency USD EU RoHS Indicator Y Gross Weight Per Pack 1069.9900 lb Gross Weight per Pack Metric 485.34 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 4.7244 in Height [Metric] 11.9380 cm Item Group 00080 Length 3.5433 in Length [Metric] 8.8900 cm Material FIBERGLASS FILLED THERMOSET MOLDING MATERIAL. Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=399219&lang=en-us Number Of Poles 2 Operating Temperature CALIBRATED FOR USE AT 40 DEGREES C. SEE DATA BULLETIN 0100DB0101 FOR RE-RATING INFORMATION. Phase 1 Returnable N Standard UL LISTED - CSA CERTIFIED Sub Brand QO Type MINIATURE CIRCUIT BREAKER UNSPSC 39121603 UPC 11 78590108828 UPC 12 785901088288 Warranty Description Contractual Warranty:18 months Width 3.1496 in Width [Metric] 8.1280 cm Brand Square D™ Manufacturer Schneider Electric Amperage Rating 30 A Interrupt Rating 10kA Voltage Rating 120 VAC Residential and Light Commercial, Commercial and Industrial Circuit Protection, Overcurrent Protection, Short Circuit Protection, Parallel and Series Arc Fault Protection and Ground Fault Protection Applications SWITCH NEUTRAL PLUG-ON Designed for superior safety, quality, and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space - compact 3/4 in W design for small system footprint Faster installation - fewer connections Frees gutter space - no pigtails with the innovative plug-on neutral design Easier troubleshooting - time saver diagnostics provide additional circuit information at the touch of a button
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QO230SWN1021 |
| Application | Residential and Light Commercial, Commercial and Industrial Circuit Protection, Overcurrent Protection, Short Circuit Protection, Parallel and Series Arc Fault Protection and Ground Fault Protection Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QO230SWN1021 |
| Connection | PRESSURE PLATE #14 TO #8 AWG(AL/CU) |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 1069.9900 lb |
| Gross Weight per Pack Metric | 485.34 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 4.7244 in |
| Height [Metric] | 11.9380 cm |
| Item Group | 00080 |
| Length | 3.5433 in |
| Length [Metric] | 8.8900 cm |
| Material | FIBERGLASS FILLED THERMOSET MOLDING MATERIAL. |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=399219&lang=en-us |
| Number Of Poles | 2 |
| Operating Temperature | CALIBRATED FOR USE AT 40 DEGREES C. SEE DATA BULLETIN 0100DB0101 FOR RE-RATING INFORMATION. |
| Phase | 1 |
| Returnable | N |
| Standard | UL LISTED - CSA CERTIFIED |
| Sub Brand | QO |
| Type | MINIATURE CIRCUIT BREAKER |
| UNSPSC | 39121603 |
| UPC 11 | 78590108828 |
| UPC 12 | 785901088288 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 3.1496 in |
| Width [Metric] | 8.1280 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 30 A |
| Interrupt Rating | 10kA |
| Voltage Rating | 120 VAC |
| Residential and Light Commercial, Commercial and Industrial Circuit Protection, Overcurrent Protection, Short Circuit Protection, Parallel and Series Arc Fault Protection and Ground Fault Protection Applications |
| SWITCH NEUTRAL PLUG-ON |
| Designed for superior safety, quality, and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space - compact 3/4 in W design for small system footprint |
| Faster installation - fewer connections |
| Frees gutter space - no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting - time saver diagnostics provide additional circuit information at the touch of a button |
