Square D™ PowerPact™ JDM36250 Type JDM Molded Case Circuit Breaker, 600 VAC/250 VDC, 250 A, 3 Poles
Molded Case Circuit Breakers
PDW~9355957
MFG #: JDM36250
Square D™
0.00000
/ ea
Square D™ PowerPact™ Molded Case Circuit Breaker, Type JDM, 600 VAC/250 VDC, 250 A, 50/60 Hz, 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC Interrupt, J Frame, Thermal Magnetic Trip, 1250 to 2500 A Trip, 3 Poles, 3-Phase, Line Lugs/Load Nut, 3/0 AWG to 350 kcmil Al/Cu Wire, NEMA AB1, 104 deg F, 7.52 in H x 4.12 in W x 5 in D
- Brochure URL - 11003_35R1PTDFMVK20N68.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_86e26fd7091d91eac4712e605cbef2835e4eb44b75b1f59c013fd6082b480e4e.pdf(Catalog URL)
- Compliance Cert URL - Square_D_JDA261502_Compliance_Certificate.pdf(Compliance Cert URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_YV3EWLGDB1KPRFOZ.pdf(Service Manual URL)
- Service Manual URL - 11003_Z7TW5GLP40EVI8H2.pdf(Service Manual URL)
- Spec Sheet URL(Spec Sheet URL)
- Spec Sheet URL - 11003_S2GFCWNOK3DZ679B.pdf(Spec Sheet URL)
- Tech Bulletin URL - files?p_enDocType=Data+Bulletin&p_File_Name=0600DB1604.pdf(Tech Bulletin URL)
- Tech Drawing URL - files?p_enDocType=Technical Drawing&p_File_Name=50-09.pdf(Tech Drawing URL)
- Tech Drawing URL - 11003_CKU5AF7YLZ9SWVGB.pdf(Tech Drawing URL)
- User Manual URL - 11003_X4QGCHKPU1SLW5TD.pdf(User Manual URL)
- User Manual URL - 11003_KMJFTUEYA5HS02OZ.pdf(User Manual URL)
- Tech Drawing URL - 11003_BFDSCUWEA6K9QLRI.pdf(Tech Drawing URL)
- Video - https://www.youtube.com/embed/8QrMlzB1bxs(Video)
- Applications
- Features
| Distribution |
| UNIT MOUNT |
| Rated current from 70 to 250 A |
| Breaking capacity from 18 to 65 kA at 480 VAC |
| Common accessories and auxiliaries with other PowerPact™ frames |
| 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating |
| Easy to install, extremely versatile, a wide variety of terminal |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
