Square D™ JDP36175 Molded Case Circuit Breaker, 600 VAC, 175 A, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ JDP36175 Molded Case Circuit Breaker, 600 VAC, 175 A, 3 Poles, Thermal Magnetic Trip
SKUPDW~6404840
MFGR #JDP36175
Price Not Available
List: The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
The PowerPact™ H, J and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic™ electronic trip units. L-frame circuit breakers are available with Micrologic™ electronic trip units only. H and J-frame circuit breakers with thermal-magnetic trip units contain individual thermal (overload) and instantaneous (short circuit) sensing elements in each pole. The amperage ratings of the thermal trip elements are calibrated at 104 deg F free air ambient temperature. Per the National Electric Code® (NEC®) and the Canadian Electrical Code®, standard circuit breakers may only be applied continuously at up to 80% of their rating. Circuit breakers rated for 100% operation are available but require specially-designed enclosures and 194 deg F rated wire.
Actuator Type Toggle Alternate Catalog Number JDP36175 ARRA Compliant N Buy American Compliant N Catalog Number JDP36175 Connection Terminal nut, line;lugs, load; AWG 4...AWG 4/0 aluminium/copper terminal Connection Type Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 4.12 in W x 4.36 in D EU RoHS Indicator Y Frame J Frame Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0204 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 in Item Group 01110 Length 21.4330 in Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425323&lang=en-us Mounting Type Surface Number Of Poles 3 Phase 3 pH Returnable Y Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489IEC 60947-2CSA C22.2 No. 5Federal Specification W-C-375B/GENNEMA AB1NMX J-266CCC/CE Markedeccn: EAR99 Temperature Rating 104 °F Trip Range 875 to 1750 A Type 80% Rated UNSPSC 39121616 UPC 11 78590194712 UPC 12 785901947127 Warranty Description Contractual Warranty:18 months Width 18.4150 in Wire Size 4 to 4/0 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 175 A Interrupt Rating 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC UNIT MOUNT Rated current from 70 to 250 A Breaking capacity from 18 to 65 kA at 480 VAC Common accessories and auxiliaries with other PowerPact™ frames 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | JDP36175 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JDP36175 |
| Connection | Terminal nut, line;lugs, load; AWG 4...AWG 4/0 aluminium/copper terminal |
| Connection Type | Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 4.12 in W x 4.36 in D |
| EU RoHS Indicator | Y |
| Frame | J Frame |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0204 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 in |
| Item Group | 01110 |
| Length | 21.4330 in |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425323&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | Y |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489IEC 60947-2CSA C22.2 No. 5Federal Specification W-C-375B/GENNEMA AB1NMX J-266CCC/CE Markedeccn: EAR99 |
| Temperature Rating | 104 °F |
| Trip Range | 875 to 1750 A |
| Type | 80% Rated |
| UNSPSC | 39121616 |
| UPC 11 | 78590194712 |
| UPC 12 | 785901947127 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Wire Size | 4 to 4/0 AWG |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 175 A |
| Interrupt Rating | 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC |
| UNIT MOUNT |
| Rated current from 70 to 250 A |
| Breaking capacity from 18 to 65 kA at 480 VAC |
| Common accessories and auxiliaries with other PowerPact™ frames |
| 25 kA at 240 VAC, 18 kA at 480 VAC, 14 kA at 600 VAC, 20 kA at 250 VDC interrupt rating |
