Square D™ EDB36060 Standard Molded Case Circuit Breaker, 600Y/347 VAC, 60 A, 14 kA Interrupt, 3 Poles
Molded Case Circuit Breakers
316868
MFG #: EDB36060
Square D™
663.03000
/ ea
Square D EDB36060 MOLDED CASE CIRCUIT BREAKER 600V 60A,2.94 inches,25 kAIC 240 Vac 18 kAIC 480 Vac,3 phase,3 pole,4.05 inches,5.66 inches,50/60 Hz,60 A,600Y/347 Vac,Bolt-On,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,E-Frame,Lugs (1) 14 AWG-2/0 Al or Cu,Molded Case Circuit Breaker,NF Branch Circuit Breakers (Bolt-on),NF Panelboard,Provides overload and short circuit protection,Thermal Magnetic,Thermoset composite resin,UL Listed - CSA Certified,http//cisnt06.c076.us.schneider-electric.com/pubs/Circuit20Protection/Molded20Case20Circuit20Breakers/012520A20Frame20EDB-EGB-EJB/515-4.pdf
- 360 Degree View URL - 360(360 Degree View URL)
- 360 Degree View URL - index.html?pid=11003&id=8100001360Den&ext=webp(360 Degree View URL)
- Brochure URL - 11003_FC8OLTS5M7ZUQ90G.pdf(Brochure URL)
- Brochure URL - 11003_HEG1U8LF92ZOSQD5.pdf(Brochure URL)
- Compliance Cert URL - Schneider_Electric_EDB36060_Compliance_Certificate.pdf(Compliance Cert URL)
- Install Instructions 1 URL - 11003_W405MTQD91NUXV7Z.pdf(Install Instructions 1 URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_6YTNP01EFUSQGWA7.pdf(Service Manual URL)
- Spec Sheet URL - 11003_68DQK4V5P2NGWX1C.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_HUL65GPVRKXTJW9Z.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_AFD38RVZSQW5KO1L.pdf(Tech Drawing URL)
- Tech Bulletin URL - 11003_IBUNZRTP0GWX4CQM.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_5YW9XIA8JPH0MZG2.pdf(Tech Drawing URL)
- Applications
- Features
| HACR rated; NF panelboard |
| BOLT-ON |
| 14 - 2/0 AWG copper, 12 - 2/0 AWG aluminum |
| 25 kA at 120 VAC, 25 kA at 120/240 VAC, 25 kA at 240 VAC, 18 kA at 480Y/347 VAC, 14 kA at 600Y/347 VAC |
| 630 A hold, 1800 A trip |
| VISI-TRIP trip indication |
| For use with NF panelboards |
| Standard |
