Sentron™ ED22B090 Type ED2 Molded Case Circuit Breaker With Load Lugs, 125/250/240 VDC, 90 A, 10 kA Interrupt, 2 Poles
Molded Case Circuit Breakers
994212
MFG #: ED22B090
Siemens
1393.62000
/ ea
Sentron™ Molded Case Circuit Breaker, Type ED2, 125/250/240 VDC, 90 A, 50/60 Hz, 10 kA Interrupt, ED Frame, Thermal Magnetic Trip, 2 Poles, 1-Phase, Line Lug, 40 deg C, 3 in L x 7 in W x 6 in H
- Catalog URL - IDW_DOCUMENT_1537663746854.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - SIE_DW_ED-2Pole-Breaker-Frame.DWG(Computer~Aided [CAD|BIM] Model URL)
- http://www.sea.siemens.com(Seller Home Page URL)
- Spec Sheet URL - DatasheetService?format=PDF&caller=EGH&mlfbs=US2:ED22B090&language=en(Spec Sheet URL)
- User Manual URL - man(User Manual URL)
- Applications
- Features
| Standard 40C Breaker |
| N/A |
| Varying actuator |
