Schneider Electric PowerPact™ MGP26800 Molded Case Circuit Breaker, 600 VAC, 800 A, 2 Poles
Molded Case Circuit Breakers
237622
MFG #: MGP26800
Square D™
14056.30000
/ ea
Schneider Electric MGP26800 MOLDED CASE CIRCUIT BREAKER 600V 800A,12.86 in,18 kA 600 VAC,2-Poles,50/60 Hz,600 V,8.05 in,8.27 in,800 A,Line Lug,Lugs OFF end Terminal Nut Kit On end,M- Frame,Molded Case Circuit Breaker,PowerPact,UL Certified, IEC Rated,thermal-magnetic
- Catalog URL - Square_D_MGA263002_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=m800-3p-lug.dwg(Computer~Aided [CAD|BIM] Model URL)
- Service Manual URL - files?p_enDocType=End of life manual&p_File_Name=ENVEOLI1312003EN.pdf(Service Manual URL)
- Spec Sheet URL(Spec Sheet URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Install Instructions URL - Square_D_MGA263002_Instruction_Sheet.pdf(Install Instructions URL)
- Tech Drawing URL - files?p_enDocType=Technical Drawing&p_File_Name=m800-3p-lug.dwg(Tech Drawing URL)
- Features
| LUGS OFF END TERMinAL NUT KIT ON END |
| Provide overload and short circuit protection |
| Are true RMS sensing devices |
| Provide means to manually disconnect power to the circuit |
| Provide enhanced coordination by their adjustabilit |
| Provide high interrupting ratings and withstand ratings |
