Schneider Electric GFP Ground Fault Protector, 230/240/277/400/415/480Y VAC, 10 kA, 2 Poles, Instantaneous Trip
Ground-Fault Circuit Breakers
584191
MFG #: 60969
Square D™
844.94000
/ ea
Schneider Electric 60969 GFP 2P 25A 30mA AC SiE 480Y/277V,230/400 V AC 50 Hz-240/415 V AC 50 Hz-240 V AC 60 Hz-480Y/277 V AC 60 Hz,230/400 V AC 50 Hz-240/415 V AC 50 Hz-240 V AC 60 Hz-480Y/277 V AC 60 Hz,50/60 Hz,GFP,GFP,earth leakage protection,ground fault protector
- Brochure URL - 5430777ee56dfe2ed5d0f860e8d076d8ddee6ea1.pdf(Brochure URL)
- Catalog URL - Schneider_Electric_60972_Brochure.pdf(Catalog URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL - be2a0c66611412b329e8ac89d521563043dbb2b1.pdf(Spec Sheet URL)
- Computer~Aided [CAD|BIM] Model URL - a568889677b85294c8b711e5e740e1e6c63af607.zip(Computer~Aided [CAD|BIM] Model URL)
- Install Instructions URL - Square_D_60969_Installation.pdf(Install Instructions URL)
- Video - https://youtube.com/embed/CsHMIcmXiO0(Video)
- Tech Drawing URL - ab0b973a802daa48fc970565afecc0c101e8610a(Tech Drawing URL)
- Features
| FAULT INDICATION,PADLOCKING IN OFF POSITION |
| 240 VAC/480Y/277 VAC at 60 Hz, 230/400 VAC/240/415 VAC At 50 Hz |
| AC network type |
| 30 mA earth leakage sensitivity |
| Instantaneous earth-leakage protection time delay |
| Class AC SiE earth-leakage protection class |
| 240 VAC at 60 Hz, 480Y/277 VAC at 60 Hz, 230/400 VAC at 50 Hz, 240/415 VAC at 50 Hz system voltage |
| 6 kV rated impulse withstand voltage |
| Toggle control type |
| Fault indication local signaling |
| (4) 9 mm pitches |
| 20000 cycles mechanical durability |
| Padlockable provision |
| Padlocking in Off position locking options description |
| Tunnel type terminals 0 to 0.05 sq-in flexible and rigid |
| 0.14 in wire stripping length |
| IPxx B, IP20, IP40 conforming to IEC 60529 degree of protection |
| 2 tropicalisation |
| 95% at 131 deg F relative humidity |
| -40 to 158 deg F ambient air temperature for storage |
