Schneider Electric C60N Miniature Circuit Breaker, 240 VAC/60 VDC, 1.5 A, 10 kA Interrupt, 1 Pole, D-Curve Thermal Magnetic Trip
Miniature Circuit Breakers
669986
MFG #: 60119
Square D™
137.81000
/ ea
Schneider Electric 60119 MINIATURE CIRCUIT BREAKER 120V 1.5A,1.5A,10 to 14 times ampere rating,12...240 V AC-125 V DC-60 V DC,12...240 V AC-125 V DC-60 V DC,35mm DIN rail,73 mm,Box Lug Box Lug,C60,C60 UL489,miniature circuit-breaker,C60,Multi 9,D,IP40 (Case) - IP20 (Terminals),UL 489 - CSA C22.2 No.5
- Brochure URL - ba740caa25d0c72398ec4a8649e3e1642c0589f6.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_3055cef7572f2db8c82c538c2984d4b8dd759efbe581e5c69cf67b443886c5b0.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - 82379be17520b5463b8e9078a3df679d8a0b1834(Computer~Aided [CAD|BIM] Model URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL - eb20308c55d73b579c0f6338b719cdf008fd75c2.pdf(Spec Sheet URL)
- Tech Bulletin URL - eb20308c55d73b579c0f6338b719cdf008fd75c2.pdf(Tech Bulletin URL)
- Tech Drawing URL - 6736349dc48ed3502ea20df09baa9f465f8572e0(Tech Drawing URL)
- Features
| ON/OFF INDICATION |
| Fast closing allows increased withstand to the high inrush currents of some loads |
| Trip free mechanism contacts cannot be held in the I-ON position when the circuit breaker is tripped automatically |
| Positive indication of contact disconnect |
| Green mechanical indication on front face of circuit breaker shows that all poles are open |
| Allows locking in O-OFF position using padlock attachment |
