Schneider Electric 601 Miniature Circuit Breaker, 120/240 VAC/60/125 VDC, 4 A, 10 kA Interrupt, 2 Poles
Miniature Circuit Breakers
288005
MFG #: 60139
Square D™
237.21000
/ ea
Schneider Electric 60139 MINIATURE CIRCUIT BREAKER 240V 4A,35mm DIN rail,4A,60 V DC-125 V DC-12...240 V AC,60 V DC-125 V DC-12...240 V AC,7 to 10 times ampere rating,73 mm,Box Lug Box Lug,C,C60,C60 UL489,miniature circuit-breaker,C60,Multi 9,IP40 (Case) - IP20 (Terminals),UL 489 - CSA C22.2 No.5
- Brochure URL - 5430777ee56dfe2ed5d0f860e8d076d8ddee6ea1.pdf(Brochure URL)
- Catalog URL - Square_D_60118_Catalog.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - b1cec0c0d2ec44914809d42befcd050c64a76d41(Computer~Aided [CAD|BIM] Model URL)
- Spec Sheet URL - 16ec1a97180ac667da55ac5c0024fb77b20c333e.pdf(Spec Sheet URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Tech Bulletin URL - eb20308c55d73b579c0f6338b719cdf008fd75c2.pdf(Tech Bulletin URL)
- Tech Drawing URL - 017277522a6427fd31212032e527dd7f311c75c1.wmf(Tech Drawing URL)
- Features
| ON/OFF INDICATION |
| For typical loads |
| Increased installation flexibility with standard box lugs or optional ring terminals |
| Allows easy front-mounting and rear wiring when using ring terminals |
| A wide range of electrical and mechanical accessories |
| Suitable for reverse feeding |
| Trip-free mechanism |
| Positive indication of contact disconnect |
| For branch circuit protection |
| Eliminates concerns and uncertainty of using a UL 1077 device where a UL 489 device is required |
| Replaces fuses in low-ampere range 17 ratings up to 35 A |
| Thermal magnetic protection |
| 35 mm DIN rail |
| 2.5 Nm tightening torque |
| 2000 m operating altitude |
| Tunnel type terminal, top or bottom wire wires (14 to 4 AWG) |
| 14 mm top or bottom wire stripping length |
