Littelfuse®
Littelfuse® H229001P SLO-BLO 2AG TYPE GLA
Custom_Product_Images_Illustration
Littelfuse®
Littelfuse® H229001P SLO-BLO 2AG TYPE GLA
SKUPDW~4880343
MFGR #H229001P
Your Cost: $4.73/ea
List: Littelfuse,313 Series,3AG Slo-Blo
Littelfuse,313 Series,3AG Slo-Blo
Alternate Catalog Number 0229001.HXP Application Telecom ARRA Compliant N Body Size 0.19 in Dia x 0.59 in L Body Type Cartridge Buy American Compliant N Catalog Number H229001P Country of Origin MX Currency USD EU RoHS Indicator C Gross Weight Per Pack 1 lb Harmonization Tariff Schedule Code 8536100020 Indicating|Non~Indicating Non-Indicating Material Glass Mounting Type Holder Response Time 3 to 20 s Series 229 Standard UL Standard 248-14 Standards RoHS CompliantUL 248-14 File No. E10480CSA File No. 29862CE CertifiedPSE CertifiedPPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer Sub Brand 229 Series Type Slo Blo UNSPSC 39121627 UPC 11 07945891542 UPC 12 079458915426 Stock Status NONSTOCK Brand Littelfuse® Manufacturer Littelfuse Inc. Amperage Rating 1 A Interrupt Rating 35 A Voltage Rating 250 VAC Telecom Fuse with Indicating Option 229 series 2AG fuses have time delay of 313 series 3AG fuses in less than one-third of the space They provide superior protection for inductive loads such as motors, transformers and solenoids Use whenever time delay fuses are indicated Guesswork and time consuming circuit testing is eliminated This unique design offers the same quality performance characteristics as the standard 2AG fuse design Lead-free 35 A at 250 VAC, 80 A at 310 VAC, 10 kA at 125 VAC/VDC interrupt rating 4 hr at 100%, 1 hr at 135%, 3 to 20 s at 200% response time
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | 0229001.HXP |
| Application | Telecom |
| ARRA Compliant | N |
| Body Size | 0.19 in Dia x 0.59 in L |
| Body Type | Cartridge |
| Buy American Compliant | N |
| Catalog Number | H229001P |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | C |
| Gross Weight Per Pack | 1 lb |
| Harmonization Tariff Schedule Code | 8536100020 |
| Indicating|Non~Indicating | Non-Indicating |
| Material | Glass |
| Mounting Type | Holder |
| Response Time | 3 to 20 s |
| Series | 229 |
| Standard | UL Standard 248-14 |
| Standards | RoHS CompliantUL 248-14 File No. E10480CSA File No. 29862CE CertifiedPSE CertifiedPPROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer |
| Sub Brand | 229 Series |
| Type | Slo Blo |
| UNSPSC | 39121627 |
| UPC 11 | 07945891542 |
| UPC 12 | 079458915426 |
| Stock Status | NONSTOCK |
| Brand | Littelfuse® |
| Manufacturer | Littelfuse Inc. |
| Amperage Rating | 1 A |
| Interrupt Rating | 35 A |
| Voltage Rating | 250 VAC |
| Telecom |
| Fuse with Indicating Option |
| 229 series 2AG fuses have time delay of 313 series 3AG fuses in less than one-third of the space |
| They provide superior protection for inductive loads such as motors, transformers and solenoids |
| Use whenever time delay fuses are indicated |
| Guesswork and time consuming circuit testing is eliminated |
| This unique design offers the same quality performance characteristics as the standard 2AG fuse design |
| Lead-free |
| 35 A at 250 VAC, 80 A at 310 VAC, 10 kA at 125 VAC/VDC interrupt rating |
| 4 hr at 100%, 1 hr at 135%, 3 to 20 s at 200% response time |
