Littelfuse® FLNR035ID POWR-GARD® FLNR Current Limiting Time Delay Fuse, 35 A, 250 VAC/125 VDC, 200/20 kA Interrupt, Class RK5
Custom_Product_Images_Illustration
Littelfuse® FLNR035ID POWR-GARD® FLNR Current Limiting Time Delay Fuse, 35 A, 250 VAC/125 VDC, 200/20 kA Interrupt, Class RK5
SKU8972
MFGR #FLNR035ID
Your Cost: $14.46/ea
List: Littelfuse FLNR series fuses have been the superior UL Class RK5 dual-element time-delay fuses, and are the most widely used class of fuses. FLNR series fuses provide excellent protection for all types of circuits especially those containing motors. However, users and specifiers should consider the significant benefits offered by Indicator fuses.
Littelfuse FLNR series fuses have been the superior UL Class RK5 dual-element time-delay fuses, and are the most widely used class of fuses. FLNR series fuses provide excellent protection for all types of circuits especially those containing motors. However, users and specifiers should consider the significant benefits offered by Indicator fuses.
Alternate Catalog Number FLNR035.TXID Application General purpose ARRA Compliant N Body Size 13/16 in Dia x 3 in L Buy American Compliant N Catalog Number FLNR035ID Country of Origin MX Currency USD Element Dual EU RoHS Indicator N Frequency Rating 50/60 Hz Gross Weight Per Pack 0.1350 lb Gross Weight per Pack Metric 0.06 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536100040 Indicating|Non~Indicating Indicating Item Group 079458-4O Material Fiber Mounting Type Holder Rejection|Non~Rejection Rejection Response Time 10 s Series FLNR Standard Standard 248-12 UL Listed/CSA Standards RoHS CompliantUL 248-12E81895CSA LR29862Federal Specification WF-1814PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer Sub Brand POWR-GARD FLNR Series Terminal Type Ferrule Type Class RK5 UNSPSC 39121627 UPC 11 07945802380 UPC 12 079458023800 Stock Status NORMALLY STOCKED Brand Littelfuse® Manufacturer Littelfuse Inc. Amperage Rating 35 A Body Type Cylindrical Class RK5 Interrupt Rating 200/20 kA Voltage Rating 250 VAC/125 VDC General Purpose Time-Delay Reduce down time - A glance at the indicating window of a FLNR indicator fuse pinpoints open fuses immediately If the window is dark, the fuse has opened, it's that simple No fuse testing required Machine operators can immediately determine that there is an open fuse and request maintenance personnel to bring the proper replacement Reduce nuisance opening - FLNR indicator fuses have superior time delay and cycling characteristics which can lengthen fuse life and decrease needless opening Reduce fuse inventory - Because FLNR indicator fuses have superior performance characteristics they can be used on a variety of applications, thus decreasing fuse inventory Reduce equipment damage - FLNR indicator fuses have superior overload and short circuit protection which can reduce equipment damage Reduce accidents - The FLNR indicator fuses improve safety by minimizing exposure to live circuits Unlike other forms of blown fuse indication, indicator fuses provide built-in blown fuse indication with the power on or off No second guessing whether a light means a good or bad fuse and no current going across a blown fuse to power a lighted accessory
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | FLNR035.TXID |
| Application | General purpose |
| ARRA Compliant | N |
| Body Size | 13/16 in Dia x 3 in L |
| Buy American Compliant | N |
| Catalog Number | FLNR035ID |
| Country of Origin | MX |
| Currency | USD |
| Element | Dual |
| EU RoHS Indicator | N |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.1350 lb |
| Gross Weight per Pack Metric | 0.06 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536100040 |
| Indicating|Non~Indicating | Indicating |
| Item Group | 079458-4O |
| Material | Fiber |
| Mounting Type | Holder |
| Rejection|Non~Rejection | Rejection |
| Response Time | 10 s |
| Series | FLNR |
| Standard | Standard 248-12 UL Listed/CSA |
| Standards | RoHS CompliantUL 248-12E81895CSA LR29862Federal Specification WF-1814PROP65: This product can expose you to chemicals including nickel, which is known to the State of California to cause cancer |
| Sub Brand | POWR-GARD FLNR Series |
| Terminal Type | Ferrule |
| Type | Class RK5 |
| UNSPSC | 39121627 |
| UPC 11 | 07945802380 |
| UPC 12 | 079458023800 |
| Stock Status | NORMALLY STOCKED |
| Brand | Littelfuse® |
| Manufacturer | Littelfuse Inc. |
| Amperage Rating | 35 A |
| Body Type | Cylindrical |
| Class | RK5 |
| Interrupt Rating | 200/20 kA |
| Voltage Rating | 250 VAC/125 VDC |
| General Purpose |
| Time-Delay |
| Reduce down time - A glance at the indicating window of a FLNR indicator fuse pinpoints open fuses immediately |
| If the window is dark, the fuse has opened, it's that simple |
| No fuse testing required |
| Machine operators can immediately determine that there is an open fuse and request maintenance personnel to bring the proper replacement |
| Reduce nuisance opening - FLNR indicator fuses have superior time delay and cycling characteristics which can lengthen fuse life and decrease needless opening |
| Reduce fuse inventory - Because FLNR indicator fuses have superior performance characteristics they can be used on a variety of applications, thus decreasing fuse inventory |
| Reduce equipment damage - FLNR indicator fuses have superior overload and short circuit protection which can reduce equipment damage |
| Reduce accidents - The FLNR indicator fuses improve safety by minimizing exposure to live circuits |
| Unlike other forms of blown fuse indication, indicator fuses provide built-in blown fuse indication with the power on or off |
| No second guessing whether a light means a good or bad fuse and no current going across a blown fuse to power a lighted accessory |
