Leviton® SmartlockPro® AFTR1 Self-Grounding AFCI Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Brown
Custom_Product_Images_Illustration
Leviton® SmartlockPro® AFTR1 Self-Grounding AFCI Receptacle, 125 VAC, 15 A, 2 Poles, 3 Wires, Brown
SKU715738
MFGR #AFTR1
Your Cost: $33.79/ea
List: The SmartlockPro® Outlet Branch Circuit (OBC) AFCI Receptacle offers advanced technology to help protect against electrical fires resulting from arc-faults. Designed to detect a wide range of potentially hazardous arc-faults resulting from damage in branch circuit wiring as well as extensions to branches such as appliances and cord sets, the OBC AFCI responds by interrupting power. This helps reduce the likelihood of the home's electrical system being an ignition source of a fire. Often unseen, arc-faults can occur anywhere in the home's electrical system including within walls, at loose electrical connections or within electrical cords accidently damaged by impinging furniture. AFCIs are now required by the National Electrical Code® in many areas of the home.
The SmartlockPro® Outlet Branch Circuit (OBC) AFCI Receptacle offers advanced technology to help protect against electrical fires resulting from arc-faults. Designed to detect a wide range of potentially hazardous arc-faults resulting from damage in branch circuit wiring as well as extensions to branches such as appliances and cord sets, the OBC AFCI responds by interrupting power. This helps reduce the likelihood of the home's electrical system being an ignition source of a fire. Often unseen, arc-faults can occur anywhere in the home's electrical system including within walls, at loose electrical connections or within electrical cords accidently damaged by impinging furniture. AFCIs are now required by the National Electrical Code® in many areas of the home.
Application Residential, Commercial ARRA Compliant C Buy American Compliant C Catalog Number AFTR1 Connection Back Wired;Side Wired Country of Origin CN Currency USD Dimensions 4.21 in H x 1.68 in W x 1.27 in D EU RoHS Indicator C Frequency Rating 60 Hz Gross Weight Per Pack 0.3800 lb Gross Weight per Pack Metric 0.17 Gross Weight UOM Metric kg Height 6.2500 in Horsepower 1 hp Length 9.2500 in Material Polycarbonate Mounting Wallplate NEMA Rating NEMA 5-15R Number Of Poles 2 Operating Temperature -35 to +66 °C Size 1.68 W x 4.21 H x 1.27 D IN Standard CSA Certified (C22.2 42);NEMA (WD-6);CSA Certified (M-02A);ANSI (C-73);UL Listed (498);NOM Certified (057);UL Listed (1699 A E342815);UL Fed Spec (WC-596) Standards ANSI C-73, CSA C22.2 No 42, CSA Technical Information Letter No M-02A, NOM 057, NEMA WD-6, UL1699.A File No E342815, UL498, UL Fed Spec WC-596 Sub Brand SmartlockPro Temperature Rating -35 to 66 °C Terminal Type Back/Side Wired Type Duplex Outlet;Arc Fault Circuit Interrupter UNSPSC 39121633 UPC 11 07847757491 UPC 12 078477574911 Stock Status NONSTOCK Brand Leviton® Manufacturer Leviton Manufacturing Co., Inc. Amperage Rating 15 A Color Brown Number of Wires 3 Voltage Rating 125 V Residential, Commercial Device Design Reduces Nuisance Tripping, Impact-Resistant Thermoplastic Cover and Body, Superior Resistance to Electrical Surges and Over-Voltages, Compatible with all Decora Devices and Wallplates, Packed with Coordinating Wallplate, with Led Indicator, Backed by Leviton's Limited Two-Year Product Warranty Use of TEST and RESET buttons is similar to traditional GFCI receptacles of which consumers have become familiar with, this translates into greater acceptance of the technology and a more user-friendly platform Automatically tests the AFCI every time the RESET button is depressed; the AFCI will not reset if the AFCI circuit is not functioning properly TR symbol indicates the device's compliance with the latest NEC® requirements for tamper-resistant receptacles in residences and childcare facilities Device design reduces nuisance tripping Impact-resistant thermoplastic cover and body Superior resistance to electrical surges and over-voltages Terminals allow for easy wiring options - back and side wire capable Compatible with all Decora® devices and wallplates; available in select colors Meets or exceeds UL requirements for tripping time on both series and parallel arcs Packed with coordinating wallplate (except AFRBF) Expanded wiring options with nine back-wire holes (two for each line and load connection plus one for ground with an internal clamp) OBC AFCI receptacles address the dangers associated with both types of potentially hazardous arcing - parallel and series arcing Similar to GFCIs, AFCI receptacles provide feed-through protection and are able to detect downstream parallel and series arc-faults as well as upstream series arc-faults Dielectric voltage withstands 1250 VAC per UL 1699A Back and side termination 14 to 10 AWG terminal, tamper resistant
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Application | Residential, Commercial |
| ARRA Compliant | C |
| Buy American Compliant | C |
| Catalog Number | AFTR1 |
| Connection | Back Wired;Side Wired |
| Country of Origin | CN |
| Currency | USD |
| Dimensions | 4.21 in H x 1.68 in W x 1.27 in D |
| EU RoHS Indicator | C |
| Frequency Rating | 60 Hz |
| Gross Weight Per Pack | 0.3800 lb |
| Gross Weight per Pack Metric | 0.17 |
| Gross Weight UOM Metric | kg |
| Height | 6.2500 in |
| Horsepower | 1 hp |
| Length | 9.2500 in |
| Material | Polycarbonate |
| Mounting | Wallplate |
| NEMA Rating | NEMA 5-15R |
| Number Of Poles | 2 |
| Operating Temperature | -35 to +66 °C |
| Size | 1.68 W x 4.21 H x 1.27 D IN |
| Standard | CSA Certified (C22.2 42);NEMA (WD-6);CSA Certified (M-02A);ANSI (C-73);UL Listed (498);NOM Certified (057);UL Listed (1699 A E342815);UL Fed Spec (WC-596) |
| Standards | ANSI C-73, CSA C22.2 No 42, CSA Technical Information Letter No M-02A, NOM 057, NEMA WD-6, UL1699.A File No E342815, UL498, UL Fed Spec WC-596 |
| Sub Brand | SmartlockPro |
| Temperature Rating | -35 to 66 °C |
| Terminal Type | Back/Side Wired |
| Type | Duplex Outlet;Arc Fault Circuit Interrupter |
| UNSPSC | 39121633 |
| UPC 11 | 07847757491 |
| UPC 12 | 078477574911 |
| Stock Status | NONSTOCK |
| Brand | Leviton® |
| Manufacturer | Leviton Manufacturing Co., Inc. |
| Amperage Rating | 15 A |
| Color | Brown |
| Number of Wires | 3 |
| Voltage Rating | 125 V |
| Residential, Commercial |
| Device Design Reduces Nuisance Tripping, Impact-Resistant Thermoplastic Cover and Body, Superior Resistance to Electrical Surges and Over-Voltages, Compatible with all Decora Devices and Wallplates, Packed with Coordinating Wallplate, with Led Indicator, Backed by Leviton's Limited Two-Year Product Warranty |
| Use of TEST and RESET buttons is similar to traditional GFCI receptacles of which consumers have become familiar with, this translates into greater acceptance of the technology and a more user-friendly platform |
| Automatically tests the AFCI every time the RESET button is depressed; the AFCI will not reset if the AFCI circuit is not functioning properly |
| TR symbol indicates the device's compliance with the latest NEC® requirements for tamper-resistant receptacles in residences and childcare facilities |
| Device design reduces nuisance tripping |
| Impact-resistant thermoplastic cover and body |
| Superior resistance to electrical surges and over-voltages |
| Terminals allow for easy wiring options - back and side wire capable |
| Compatible with all Decora® devices and wallplates; available in select colors |
| Meets or exceeds UL requirements for tripping time on both series and parallel arcs |
| Packed with coordinating wallplate (except AFRBF) |
| Expanded wiring options with nine back-wire holes (two for each line and load connection plus one for ground with an internal clamp) |
| OBC AFCI receptacles address the dangers associated with both types of potentially hazardous arcing - parallel and series arcing |
| Similar to GFCIs, AFCI receptacles provide feed-through protection and are able to detect downstream parallel and series arc-faults as well as upstream series arc-faults |
| Dielectric voltage withstands 1250 VAC per UL 1699A |
| Back and side termination |
| 14 to 10 AWG terminal, tamper resistant |
