LKG PLG, 30A 125V, HUB PRO, L5-30P
Locking Plugs
462648
MFG #: L530P
Hubbell Wiring Device-Kellems
43.50000
/ ea
Hubbell-Pro locking devices provide a safe disconnect solution between an equipment load and a power source. These devices incorporate a locking interface that is engaged and disengaged simply by rotating the device assuring a safe and reliable electrical connection.
- http://www.hubbell-wiring.com/(Seller Home Page URL)
- Install Instructions 1 URL - 11456_4PIGBWMCA1NSEL9R.pdf(Install Instructions 1 URL)
- Install Instructions 1 URL - WIRING_B04250H03_INSTALLINST.pdf(Install Instructions 1 URL)
- Line Drawing URL - 11456_S7VD4AJ6PX81T5F3.pdf(Line Drawing URL)
- Line Drawing URL - WDK_L530P_DRAWING_PDF.pdf(Line Drawing URL)
- Spec Sheet URL - 11456_7PL1N09U5DVSZTFM.pdf(Spec Sheet URL)
- Spec Sheet URL - WIRING_Hubbell-PRO(Spec Sheet URL)
- Tech Drawing URL - WIRING_L530P_M11417_ACAD_DRAWING.dwg(Tech Drawing URL)
- Video - https://www.youtube.com/embed/WRvTrAHlyzk(Video)
- Applications
- Features
| Industrial/Commercial |
| Standard Product |
| Visible NEMA ratings |
| Captive assembly screws |
| Supertough® nylon body |
| Impact modified nylon blade/contact holder |
| Brass contacts/blade |
| Withstands 3500 VAC per UL 498 dielectric voltage |
| 600 VAC or 250 VDC maximum working voltage |
| Maximum 30 deg C temperature rise at full rated current after 50 cycles overload at 150% rated current for either AC or DC applications per UL 498 |
| Minimum 4.8 times rated current for 100 cycles overload |
| Terminals identified in accordance with UL 498 (brass, white, green) |
| 18 to 8 AWG flexible cord |
| Ratings and NEMA identification are permanently marked on device |
| Indoor dry unless protected by additional means |
| 10 to 8 AWG wire |
