Juno® Trac-Master™ TU12WH Circuit Track, Extruded Aluminum

Track Rails
76703 MFG #: TU 12FT WH
Juno®
93.91000 / ea
10988_39IMX6OQJVKU7W5G
Trac-Master® TU-Series low profile, 2-circuit trac sections can be surface or pendant mounted. They provide 2 separate 20-amp circuits from a single electrical feed or one 20-amp circuit controlled by 2 switches. The trac features an I-beam cross section that provides added strength and rigidity in suspended pendant applications and is compatible with a full range of feed, connector, and mounting accessories to satisfy virtually any requirement. Trac sections are available in 4, 8, and 12-foot lengths and accept all Trac-Master lampholders.
QTY
Add to Wishlist
  • Applications
  • Features
Trac Lighting
2-circuit capability offers the flexibility of individual circuit control for combining dual lighting effects along a single trac
Two 20-amp circuits provide maximum switching flexibility; in long trac runs, the increased capacity eliminates 50-percent of the feed points
Extruded aluminum I-beam channel construction, finished in white, black, or silver, injection-molded polycarbonate dead-end with set screw
One-piece thermoplastic insulator ensures consistent conductor spacing for reliable electrical contact
Insulating bushings supplied at mounting hole locations to prevent shorts to the ground
Debossed polarity line provides visual cue to proper trac, trac connector, and fixture alignment
Integral raceway in top of channel accommodates pendant mounting hardware and wire routing to electrical feed
Three 12-gauge solid copper conductors, each circuit rated 20A at 120V, connectors and feeds simply push into trac sections
Standard lengths may be cut to length by the installer
