Hubbell Wiring Device-Kellems Twist-Lock® HBL3331C Extra Heavy Duty Non-Grounding Locking Plug, 125/250 VAC, 30 A, 3 Poles, 3 Wires, Black/White
Locking Devices
26351
MFG #: HBL3331C
Hubbell Wiring Device-Kellems
57.31000
/ ea
Wiring Device-Kellems Twist-Lock® Locking Plug, Extra Heavy Duty Non-Grounding, 125/250 VAC, 30 A, 3 Poles, 3 Wires, Industrial Grade, IP20 Enclosure, 0.36 to 0.93 in Cord Dia, -40 to 75 deg C, Screw Terminal, Composite, Black/White, 1.97 in Dia x 2.75 in L
- http://www.hubbell-wiring.com/(Seller Home Page URL)
- Install Instructions 1 URL - 11456_D84MEZW2BFLJTCGY.pdf(Install Instructions 1 URL)
- Spec Sheet URL - WIRING_HBL3331C_spec.pdf(Spec Sheet URL)
- Warranty URL - 11456_Y8PS6T0FNOGH3Q75.pdf(Warranty URL)
- Spec Sheet URL - 11456_VKOWUEFH01RA9PXM.pdf(Spec Sheet URL)
- Install Instructions 1 URL - WIRING_PD1652_INSTALLINST.pdf(Install Instructions 1 URL)
- Warranty URL - Wiring_WDK_Warranty.pdf(Warranty URL)
- Applications
- Features
| Extra Heavy Duty Industrial |
| Standard Product |
| Withstands 2000 VAC dielectric voltage |
| 10 to 8 AWG wire |
| 16 to 8 AWG stranded copper wire terminal accommodation |
| Maximum 30 deg C temperature rise at full rated current after 50 cycles of overload at 150% of rated current at a power factor of 75% temperature rise |
| Certified for current interrupting at full rated current interrupting |
| Terminals identified in accordance with UL 498 |
| Ribbed nylon housing provides a secure grip and impact and chemical resistance |
| Superior cord grip design protects terminations from excess strain |
| Clear, funnel shaped wire entry for ease of termination |
| Integral dust shield protects wiring chamber from dust or contaminants |
| #10-32 brass (Phillips/slotted/Robertson) terminal screws |
| Clear polycarbonate terminal retainer |
| Brass blades |
| Cold rolled steel nickel plated terminal clamp and steel nickel plated assembly screws |
| Indoor dry unless protected by additional means |
