GE UltraStart® GE454MVPS90-E-S Electronic Fluorescent Ballast, T5 Lamp, 108 to 305 VAC, Programmed/Rapid
Electronic Fluorescent Ballasts
926451
MFG #: GE454MVPS90-E-S
GE
399.88000
/ ea
GE UltraStart® Electronic Fluorescent Ballast, T5 Lamp, 227 W, 108 to 305 VAC, 50/60 Hz, Programmed/Rapid Start, -20 deg F Minimum Starting, Total Harmonic Distortion: <10%, Power Factor: >0.99, Yes Dimmable, 4 Lamps, Ballast Factor: 0.99/1.05, 55 deg C, 16-45/64 in L x 1-45/64 in W x 1-13/64 in H
- Features
| Lower maintenance costs with parallel lamp operation |
| Multi-voltage technology means a single ballast handles voltage from 108 to 305 VAC |
| Auto-restart withstands temporary losses in power without the need to cycle power |
| UltraCool™ operation 90C case rating/UL approved 55C ambient rating |
| Individual lamp end of lamp life protection - only one lamp shuts down at end of life |
| Anti-striation control for better light quality, with no striations |
| -20 deg F minimum starting temperature cold |
| The ballast should have the step dimming features and be able to provide 50% input power (+/-15%) in the dimming mode by shutdown 2 of the 4 lamps |
