Fluke® 80K-40 High Voltage Current Probe, 40000 VAC
Test Probes
393197
MFG #: 80K-40
Fluke®
342.99000
/ ea
The 80K-40 is a high voltage probe designed to extend the voltage measuring capability of an AC/DC voltmeter to 40,000 volts peak AC or DC Overvoltage Category I.
- http://www.fluke.com(Seller Home Page URL)
- http://www.fluke.com/(Seller Home Page URL)
- Install Instructions URL - ID-INS-3140R.pdf(Install Instructions URL)
- Owners Manual URL - 11095_A3VZERP14628XTIC.jpg(Owners Manual URL)
- Owners Manual URL - IDW_DOCUMENT_1520614401226.pdf(Owners Manual URL)
- Spec Sheet URL - 11095_80K-40.pdf(Spec Sheet URL)
- Spec Sheet URL - 80k40___iseng0900.pdf(Spec Sheet URL)
- Tech Drawing URL - 80k-40_c_nr-1655-1500x1000(Tech Drawing URL)
- Applications
- Features
| Extend the voltage measuring capability of an AC/DC voltmeter to 40,000 volts peak AC or DC Overvoltage Category I |
| High voltage probe designed to extend the voltage measuring capability of an AC/DC voltmeter to 40000 V peak AC or DC overvoltage category I |
| Can only be used to make measurements on energy limited circuits within equipment |
| Do not use this probe to measure high voltages on power distribution systems |
| Probe provides high accuracy when used with a voltmeter having 10 Mohm input impedance |
| Accuracy 20 kV to 35 kV - +/-1% at 20 deg C to 30 deg C, add 1% at 10 deg C <20 deg C and >30 deg C to 45 deg C, (for total measurement accuracy add accuracy specification of voltmeter being used) 0 kV to <20 kV |
| 1000:1 division ratio |
| Unusually high input impedance offered by these resistors minimizes circuit loading and thereby, optimizes measurement accuracy |
| Intended for low energy applications only |
