Burndy® YA252TC38 HYLUG™ YA-2TC 2-Hole Compression Lug Without Inspection Window, 1/0 AWG Stranded Solid Copper Conductor
Lug Compression Connectors
378390
MFG #: YA252TC38
BURNDY®
8.70000
/ ea
BURNDY'™s HYLUG™ terminals, redesigned for terminating copper conductors in a wide variety of electrical connections, including heavy-duty industrial, utility, commercial, and telecommunications applications. The HYLUG™ terminals require simple cable preparation for an easily installed permanent and inspectable cable termination. The terminals are listed by UL (UL STD. 486A) and CSA certified to 600 volts, when applied with the proper tool and die combination. The terminals may be used in applications to 35 KV.
- Brochure URL - 10969_2JR0DE1LSM84AP6Q.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_09ceaec177b448ed0a02dca3c5e28e626ff421ebfe66813ce0d0e3dc85083dd8.pdf(Catalog URL)
- http://www.burndy.com(Seller Home Page URL)
- Install Instructions 1 URL - 10969_M6IT3GNVDBYQ1JEX.pdf(Install Instructions 1 URL)
- Spec Sheet URL - 10969_PCG8K4MY2BE9JLWT.pdf(Spec Sheet URL)
- Tech Drawing URL - 10969_ID-DRW-v1-SE_208777-01.pdf(Tech Drawing URL)
- Applications
- Features
| Wire Termination |
| Features: UL Listed 90 DEG C, 600 V - 35 KV, 45 DEG And 90 DEG Angles Are Available, Temperature Rating: 90 DEG C, Wire Strip Length: 1-7/16 IN, Finish: Electro-Tin Plated, Die Index: 12, Tongue Angle: Straight, Tools, Die Set Catalog Number, And (number Of Crimps): Mechanical: MD6, OUR840, MD7-34R Tool, W25VT, W25RT, X25RT Die, (4), Hydraulic: BCT500HS, Y500CTHS Tool, W25VT, W25RT, X25RT Die, (4), Y35, Y39, Y750, PAT750 Tool, U25RT, U2CABT Die, (2), Y46 Tool, U25RT, U2CABT Die With PUADP-1 Adapter, (2), Color Code: Pink, Conductor Type: Commercial Stranded Copper, Dieless Tools (number Of Crimps): Y644HS Tool, (1), Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 Tool, (2), MRC840 Tool, (4) |
| Die set catalog number and (number of crimps): mechanical: MD6, OUR840, MD7-34R tool, W25VT, W25RT, X25RT die, (4), hydraulic: BCT500HS, Y500CTHS tool, W25VT, W25RT, X25RT die, (4), Y35, Y39, Y750, PAT750 tool, U25RT, U2CABT die, (2), Y46 tool, U25RT, U2CABT die with PUADP-1 adapter, (2), color code: pink, conductor type: commercial stranded copper, dieless tools (number of crimps): Y644HS tool, (1), Y81KFT, Y81KFTMBH, PAT81KFT-18V, MY29-3, MY29-11 tool, (2), MRC840 tool, (4) |
| Without inspection window |
