Amprobe® BAT-500 Battery Capacity Tester, 4 to 40 VAC, 40 mOhm/400 mOhm/4 Ohm/40 Ohm, 0 to 500 Ah
Battery Testers
722367
MFG #: BAT-500
Amprobe
1523.99000
/ ea
- Catalog URL - IDW_DOCUMENT_89bbc1d8ba7e606bbeba4f01221cb62cf3525cc50a7325d7ba89c243f22b2d76.pdf(Catalog URL)
- http://www.fluke.com(Seller Home Page URL)
- http://www.fluke.com/(Seller Home Page URL)
- Owners Manual URL - 11095_0L8JHS7Z1B4FWGDA.jpg(Owners Manual URL)
- Owners Manual URL - Amprobe_BAT_500_Manual.pdf(Owners Manual URL)
- Spec Sheet URL - 095969499187_01.pdf(Spec Sheet URL)
- Spec Sheet URL - 11095_Spec sheet reference.pdf(Spec Sheet URL)
- Tech Drawing URL - Ap-mo-100_03a_h(Tech Drawing URL)
- Video - http://content.amprobe.com/video-elec/Amprobe%20Battery%20Tester.html(Video)
- Applications
- Features
| electrical |
| Battery impedance tester for assessing impedance resistance, voltage, and capacity of batteries |
| Tests battery impedance to calculate its true life |
| Works with most batteries, compact storage batteries, alkaline and lead acid up to 500 Ah |
| Resistance measurement up to 40 Ohm and voltage up to 40 V |
| Tests are performed without shutting down a battery |
| Simultaneously measure battery resistance and voltage |
| Comparator function to quickly access conditions as pass, warning or fail |
| 99 memory locations to store results with read function |
| Compact and lightweight |
| RS232 PC interface to download testing results to a PC for trending/life cycle analysis |
| 1 kHz +/-10% measuring current frequency |
| 500/9600 continuous data sets memory |
| Resistance upper and lower limits and voltage through old point setting |
| 99-sets of values comparator settings |
| 50 VDC maximum input voltage |
| (6) AA size 1.5 VDC power supply or AC adapter |
| 7 hr battery life |
| Compact storage batteries/alkaline/nickel metal hydride/nickel cadmium/lithium ion/lead acid batteries |
| 25/2.5 mA/250/25 uA measurement current |
| 500/9600 data logging memory |
