Square D™ QO300 Type QO Miniature Circuit Breaker Switch, 120/240 VAC/48 VDC, 60 A, 3 Poles, Thermal Magnetic Trip
Circuit Breakers
554969
MFG #: QO300
Square D™
432.40000
/ ea
- ARRA Compliant: N
- Buy American Compliant: N
- Catalog Number: QO300
- Connection: AWG 8...AWG 2 COPPER OR ALUMINIUM,BOX LUGS
- Connection Type: Box Lug
- Country of Origin: MX
- Dimensions: 3.5 in H x 2.25 in W x 2.91 in D
- Enclosure Type: NEMA AB1
- EU RoHS Indicator: Y
- Frequency Rating: 50/60 Hz
- Gross Weight Per Pack: 1.0000 lb
- Harmonization Tariff Schedule Code: 8536509065
- Item Group: 00012
- Material: Fiberglass Filled Thermoset
- Mounting: PLUG-IN
- Mounting Type: Plug-In
- Number Of Poles: 3
- Phase: 3
- Returnable: Y
- Size: 2.25 IN,2.91 IN,3.5 IN
- Standard: UL LISTED-CSA
- Standards: ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5Federal Specification W-C-375B/GENNOM/ANCE CertifiedUL 489 File No. E84967PROP65: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Sub Brand: QO
- Temperature Rating: 104 °F
- Type: Type QO
- UNSPSC: 39122245
- UPC 11: 78590151868
- UPC 12: 785901518686
- Wire Size: 8 to 2 AWG Al/Cu
- Stock Status: NONSTOCK
- Brand: Square D™
- Manufacturer: Schneider Electric
- Amperage Rating: 60 A
- Interrupt Rating: 10 kA at 120/240 VAC/5 kA at 48 VDC
- Trip Type: Thermal Magnetic
- Voltage Rating: 120/240 VAC/48 VDC VAC
Square D QO300 NON-AUTOMATIC MINIATURE SWITCH 240V 60A,3-Pole,60A,Box Lugs #8 to #2 AWG(Al/Cu),Molded Case Switch,QO,UL Listed - CSA Certified,plug-on
- Brochure URL - e9f87798d24f515013ee85317d5fec2b373cba12.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_c5b326735eb8d1d236aee0ae89f871f8971a71ae7f56a2c5995b35a605d67649.pdf(Catalog URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL - f6ef1c184ccb390d87b644cef3e85dfd78cc1031.pdf(Spec Sheet URL)
- Warranty URL - Square_D_PA21000RC_Warranty.pdf(Warranty URL)
- Features
| BOX LUGS |
| Designed for superior safety, quality, and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space - compact 3/4 in W design for small system footprint |
| Faster installation - fewer connections |
| Frees gutter space - no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting - time saver diagnostics provide additional circuit information at the touch of a button |
