Telemecanique 9007AO2 9007 Heavy Duty Limit Switch, 600 VAC, 15 A, 1NO-1NC
Limit Switches
34385
MFG #: 9007AO2
Telemecanique Sensors
64.34000
/ ea
- Action: Linear;Snap action
- Actuating Force: 0.88 lbf;0.63 lbf
- Alternate Catalog Number: 9007AO2
- ARRA Compliant: N
- Buy American Compliant: N
- Catalog Number: 9007AO2
- Connection: 1-2 6 BINDER HEAD SCREW TERMINALS AWG 22...AWG 14)
- Connection Type: Screw Clamp
- Country of Origin: MX
- Currency: USD
- Enclosure: NEMA 1 NEMA TYPE 250
- Enclosure Type: NEMA 1/IP20
- EU RoHS Indicator: Y
- Gross Volume Per Pack: 2.80
- Gross Volume per Pack Metric: 45.88
- Gross Volume UOM: CI
- Gross Volume UOM Metric: cm3
- Gross Weight Per Pack: 0.0900 lb
- Gross Weight per Pack Metric: 40.80
- Gross Weight UOM Metric: g
- Harmonization Tariff Schedule Code: 8536509040
- Height: 1.09 in
- Height [Metric]: 2.8000 cm
- Item Group: 21491
- Length: 5.93 in
- Length [Metric]: 15.2000 cm
- Material: Plastic
- Material Composition Declaration: https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=373477&lang=en-us
- Mounting: -,BY THE BODY
- Operating Temperature: -20 to 185 °F
- Returnable: Y
- Series: 9007
- Size: 2.5 in H x 0.83 in W x 1.03 in D in
- Standard: IP20 IEC 60529
- Sub Brand: 9007AO/CO
- Type: Heavy Duty
- UNSPSC: 39122209
- UPC 11: 78590175912
- UPC 12: 785901759126
- Warranty Description: Contractual Warranty:18 months
- Width: 3.98 in
- Width [Metric]: 10.2000 cm
- Stock Status: NORMALLY STOCKED
- Brand: Telemecanique Sensors
- Manufacturer: Telemecanique Sensors
- Actuator: Vertical approach, 1 direction;Cast zinc;Spring return plunger plastic with thermoplastic end;Plunger head
- Amperage Rating: 15 A
- Contact Configuration: 1NO-1NC
- Voltage Rating: 600 VAC
- Number Of Poles: 1
Telemecanique 9007AO2 SNAP SWITCH 600VAC 15AMP AO +OPTIONS,1 N.O./1 N.C.,15A,600V,Osisense,Screw Clamp,Snap Switch,UL Listed File Number E42259 CCN NKCR - CSA Certified File Number LR25490 Class 3211-03 - CE Marked
- 360 Degree View URL - 360(360 Degree View URL)
- 3D Rendering URL - SEproductListV2.html?p=9007AO2(3D Rendering URL)
- Brochure URL - 11003_D12WSZ0Y9A4IEPQB.pdf(Brochure URL)
- Compliance Cert URL - Schneider_Electric_9049A19_Compliance_Certificate.pdf(Compliance Cert URL)
- Computer~Aided [CAD|BIM] Model URL(Computer~Aided [CAD|BIM] Model URL)
- Install Instructions 1 URL - 11003_F0GSI83JN2U15V7B.pdf(Install Instructions 1 URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Spec Sheet URL - 11003_PQ0BWAHN6RYU2DL5.pdf(Spec Sheet URL)
- Video - https://www.youtube.com/embed/UbySplDNflo(Video)
- Features
| 1...2 CABLES FOR 6 BINDER HEAD SCREW TERMINALS (AWG 22...AWG 14),IP20 CONFORMING TO IEC 60529 |
| Fixed body type |
| Plunger head |
| Cast zinc body and operator material |
| Linear movement of operating head |
| Plastic spring return plunger with thermoplastic end type of operator |
| On end switch actuation |
| 1 direction vertical approach |
| 1 to 2 cables, 6 binder head screw terminals |
| One number of pole |
| Form Z contacts form |
| 1 number of steps |
| Silver contacts |
| -20 to 185 deg F ambient air temperature for storage |
