80/20 3098 15 S 5/16-18 DOUBLE ANCHOR T- NUT SHORT ASSEMBLY
Double Anchor Fastener Assemblies
534849
MFG #: 3098
80/20
10.86000
/ ea
- Catalog Number: 3098
- Gross Weight Per Pack: 0.2100 lb
- Line Drawing Dimensions: A=1.383 B=0.309 C=0.625 D=0.25 E=0.81 F=1.469 G=0.625 H=1.437 J=5/16-18 x 1.30 SHCS
- Stock Status: NORMALLY STOCKED
- Brand: 80/20
- Manufacturer: 80/20 Inc.
- Material: Zinc
- Series: 15 Series
The double anchor fastener assembly is comprised of two socket head cap screws, two cams, and a double T-nut. This design doubles the contact between the fastener and mating profile, making an extremely strong connection. The fastener provides infinite positioning along the mating profile’s T-slot, allowing a large degree of adjustability. The double anchor fastener provides 90 degree, flush, vibration resistant connections, especially convenient where space restrictions apply and is used for profiles with open T -slots opposite each other. 80/20 recommends the double anchor fastener for non-column loaded supports to add extra strength. This connection method requires a counterbore machining service on the mounting profile. Additional Information: Cams are available separately for instances where you want to create your own custom assembly.
