Square D™ QOU2153100 Standard Miniature Circuit Breaker, 120/240 VAC, 15 A, 10 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Square D™ QOU2153100 Standard Miniature Circuit Breaker, 120/240 VAC, 15 A, 10 kA Interrupt, 2 Poles
SKUPDW~11766970
MFGR #QOU2153100
Your Cost: $102.48/ea
List: Schneider Electric,MINIATURE CIRCUIT BREAKER 120/240V 15A,10 kA,120/240 V AC,120/240 V AC,15 A,HACR rated,QOU,QOU,miniature circuit-breaker
Schneider Electric,MINIATURE CIRCUIT BREAKER 120/240V 15A,10 kA,120/240 V AC,120/240 V AC,15 A,HACR rated,QOU,QOU,miniature circuit-breaker
Alternate Catalog Number QOU2153100 Application HACR rated ARRA Compliant N Buy American Compliant N Catalog Number QOU2153100 Connection AWG 14...AWG 2 aluminium/copper;Slotted box lugs, line side;slotted box lugs, load side Country of Origin MX Currency USD Depth 2.95 in EU RoHS Indicator Y Gross Weight Per Pack 4.8081 lb Gross Weight per Pack Metric 480.81 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 9.3980 in Height [Metric] 9.3980 cm Item Group 00900 Length 5.5880 in Length [Metric] 5.5880 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=403079051&lang=en-us Number Of Poles 2 Returnable N Standard CSA-IEC-UL LISTED Sub Brand QOU Type Miniature circuit-breaker UNSPSC 39121603 Warranty Description Contractual Warranty:18 months Width 12.4460 in Width [Metric] 12.4460 cm Brand Square D™ Manufacturer Schneider Electric Amperage Rating 15 A Interrupt Rating 10 kA 120/240 V AC;10 kA 120 V AC;5 kA 48 V DC Voltage Rating 120/240 V AC;120 V AC;48 V DC HACR rated BOX LUGS LINE SIDE SLOTTED-BOX LUGS LOAD SIDE SLOTTED,SLOTTED BOX LUGS (LINE AND LOAD)
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOU2153100 |
| Application | HACR rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QOU2153100 |
| Connection | AWG 14...AWG 2 aluminium/copper;Slotted box lugs, line side;slotted box lugs, load side |
| Country of Origin | MX |
| Currency | USD |
| Depth | 2.95 in |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 4.8081 lb |
| Gross Weight per Pack Metric | 480.81 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 9.3980 in |
| Height [Metric] | 9.3980 cm |
| Item Group | 00900 |
| Length | 5.5880 in |
| Length [Metric] | 5.5880 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=403079051&lang=en-us |
| Number Of Poles | 2 |
| Returnable | N |
| Standard | CSA-IEC-UL LISTED |
| Sub Brand | QOU |
| Type | Miniature circuit-breaker |
| UNSPSC | 39121603 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 12.4460 in |
| Width [Metric] | 12.4460 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 15 A |
| Interrupt Rating | 10 kA 120/240 V AC;10 kA 120 V AC;5 kA 48 V DC |
| Voltage Rating | 120/240 V AC;120 V AC;48 V DC |
| HACR rated |
| BOX LUGS LINE SIDE SLOTTED-BOX LUGS LOAD SIDE SLOTTED,SLOTTED BOX LUGS (LINE AND LOAD) |
