Square D™ QOU Standard Miniature Circuit Breaker, 240 VAC/48 VDC, 50 A, 5 to 10 kA Interrupt, 3 Poles
Custom_Product_Images_Illustration
Square D™ QOU Standard Miniature Circuit Breaker, 240 VAC/48 VDC, 50 A, 5 to 10 kA Interrupt, 3 Poles
SKU581331
MFGR #QOU3501021
Your Cost: $522.56/ea
Square D QOU3501021 MINIATURE CIRCUIT BREAKER 240V 50A,10kA,240VAC,3P,50A,HACR rated,Line Box Lug - Load Box Lug #14-2 AWG(Al/Cu),Miniature Circuit Breaker,QOU,Standard Flush, Surface or DIN Rail (35mm),UL489 Listed - CSA 22.2 #5.1 Certified - IEC Rated 60947-2
Square D QOU3501021 MINIATURE CIRCUIT BREAKER 240V 50A,10kA,240VAC,3P,50A,HACR rated,Line Box Lug - Load Box Lug #14-2 AWG(Al/Cu),Miniature Circuit Breaker,QOU,Standard Flush, Surface or DIN Rail (35mm),UL489 Listed - CSA 22.2 #5.1 Certified - IEC Rated 60947-2
Alternate Catalog Number QOU3501021 Application HACR and Switching Duty rated ARRA Compliant N Buy American Compliant N Catalog Number QOU3501021 Connection LINE: BOX LUG - LOAD: BOX LUG #14-2 AWG(AL/CU) Connection Type Box Lug Country of Origin MX Currency USD Depth 2.95 in Dimensions 2.95 in L x 3 in W x 4.05 in H EU RoHS Indicator Y Gross Weight Per Pack 1.4100 lb Gross Weight per Pack Metric 639.57 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 10.2870 in Height [Metric] 10.2870 cm Item Group 00900 Length 7.6960 in Length [Metric] 7.6960 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=402911&lang=en-us Mounting Type DIN Rail/Flush Number Of Poles 3 Returnable N Standard UL489 LISTED - CSA 22.2 #5.1 CERTIFIED - IEC RATED 60947-2 Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedHACR RatedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Sub Brand QOU Temperature Rating 104 °F Type Standard UNSPSC 39121603 UPC 11 78590151865 UPC 12 785901518655 Warranty Description Contractual Warranty:18 months Width 7.5180 in Width [Metric] 7.5180 cm Wire Size 14 to 2 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 50 A Interrupt Rating 10 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC HACR and Switching Duty rated STANDARD FLUSH, SURFACE OR DIN RAIL (35MM) 120/208/240 VAC shunt trip 120/208/240 VAC shunt trip 120/208/240 VAC shunt trip 14 to 2 AWG aluminum/copper wire
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOU3501021 |
| Application | HACR and Switching Duty rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QOU3501021 |
| Connection | LINE: BOX LUG - LOAD: BOX LUG #14-2 AWG(AL/CU) |
| Connection Type | Box Lug |
| Country of Origin | MX |
| Currency | USD |
| Depth | 2.95 in |
| Dimensions | 2.95 in L x 3 in W x 4.05 in H |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 1.4100 lb |
| Gross Weight per Pack Metric | 639.57 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 10.2870 in |
| Height [Metric] | 10.2870 cm |
| Item Group | 00900 |
| Length | 7.6960 in |
| Length [Metric] | 7.6960 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=402911&lang=en-us |
| Mounting Type | DIN Rail/Flush |
| Number Of Poles | 3 |
| Returnable | N |
| Standard | UL489 LISTED - CSA 22.2 #5.1 CERTIFIED - IEC RATED 60947-2 |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedHACR RatedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Sub Brand | QOU |
| Temperature Rating | 104 °F |
| Type | Standard |
| UNSPSC | 39121603 |
| UPC 11 | 78590151865 |
| UPC 12 | 785901518655 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 7.5180 in |
| Width [Metric] | 7.5180 cm |
| Wire Size | 14 to 2 AWG |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 50 A |
| Interrupt Rating | 10 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| HACR and Switching Duty rated |
| STANDARD FLUSH, SURFACE OR DIN RAIL (35MM) |
| 120/208/240 VAC shunt trip |
| 120/208/240 VAC shunt trip |
| 120/208/240 VAC shunt trip |
| 14 to 2 AWG aluminum/copper wire |
