Square D™ QOH270 Type QOH Miniature Circuit Breaker, 120/240 VAC, 70 A, 42 kA at 120/240 VAC Interrupt, 2 Poles
Custom_Product_Images_Illustration
Square D™ QOH270 Type QOH Miniature Circuit Breaker, 120/240 VAC, 70 A, 42 kA at 120/240 VAC Interrupt, 2 Poles
SKU384781
MFGR #QOH270
Your Cost: $354.82/ea
List: Square D QOH270 MINIATURE CIRCUIT BREAKER 120/240V 70A,120/240 Vac,2P,3-Phase,42kA,70A,Box Lugs #8 to #2 AWG(Al/Cu),Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,HACR rated,Miniature Circuit Breaker,QO,Standard Plug-On,UL Listed - CSA Certified
Square D QOH270 MINIATURE CIRCUIT BREAKER 120/240V 70A,120/240 Vac,2P,3-Phase,42kA,70A,Box Lugs #8 to #2 AWG(Al/Cu),Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,HACR rated,Miniature Circuit Breaker,QO,Standard Plug-On,UL Listed - CSA Certified
Alternate Catalog Number QOH270 Application HACR rated ARRA Compliant N Buy American Compliant N Catalog Number QOH270 Connection Box lugs;AWG 8...AWG 2 copper or aluminium Connection Type Box Lug Country of Origin US Currency USD Dimensions 2.91 in L x 2.25 in W x 3.12 in H EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.7500 lb Gross Weight per Pack Metric 340.19 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 3.8100 in Height [Metric] 3.8100 cm Item Group 00926 Length 8.1280 in Length [Metric] 8.1280 cm Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401693&lang=en-us Mounting Type Plug-In Number Of Poles 2 Operating Temperature 40 °C Phase 3 Returnable Y Standard UL LISTED - CSA CERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedHACR RatedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Sub Brand QO Temperature Rating 104 °F Type Type QO-H Standard UNSPSC 39121603 UPC 11 78590105489 UPC 12 785901054894 Warranty Description Contractual Warranty:18 months Width 8.1280 in Width [Metric] 8.1280 cm Wire Size 8 to 2 AWG Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 70 A Interrupt Rating 42 kA Trip Type Thermal Magnetic Voltage Rating 120/240 VAC HACR rated STANDARD PLUG-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOH270 |
| Application | HACR rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QOH270 |
| Connection | Box lugs;AWG 8...AWG 2 copper or aluminium |
| Connection Type | Box Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 2.91 in L x 2.25 in W x 3.12 in H |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.7500 lb |
| Gross Weight per Pack Metric | 340.19 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.8100 in |
| Height [Metric] | 3.8100 cm |
| Item Group | 00926 |
| Length | 8.1280 in |
| Length [Metric] | 8.1280 cm |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401693&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 3 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedHACR RatedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Type | Type QO-H Standard |
| UNSPSC | 39121603 |
| UPC 11 | 78590105489 |
| UPC 12 | 785901054894 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 8.1280 in |
| Width [Metric] | 8.1280 cm |
| Wire Size | 8 to 2 AWG |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 70 A |
| Interrupt Rating | 42 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 120/240 VAC |
| HACR rated |
| STANDARD PLUG-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
