Square D™ QOB3401042 Type QOB Miniature Circuit Breaker, 120/240 VAC/48 VDC, 40 A, 3 Poles, Shunt/Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ QOB3401042 Type QOB Miniature Circuit Breaker, 120/240 VAC/48 VDC, 40 A, 3 Poles, Shunt/Thermal Magnetic Trip
SKU721224
MFGR #QOB3401042
Your Cost: $797.06/ea
Square D QOB3401042 MINIATURE CIRCUIT BREAKER 240V 40A,10 kA,240 V AC,240 V AC,3-Phase,3-Pole,40 A,Box Lugs #8 to #2 AWG(Al/Cu),HACR rated,QO,QO,UL Listed - CSA Certified,miniature circuit-breaker,standard
Square D QOB3401042 MINIATURE CIRCUIT BREAKER 240V 40A,10 kA,240 V AC,240 V AC,3-Phase,3-Pole,40 A,Box Lugs #8 to #2 AWG(Al/Cu),HACR rated,QO,QO,UL Listed - CSA Certified,miniature circuit-breaker,standard
Alternate Catalog Number QOB3401042 Amperage Rating 40 A Application HACR RATED ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number QOB3401042 Connection AWG 8...AWG 2 COPPER OR ALUMINIUM,BOX LUGS Connection Type Box Lug Country of Origin MX Currency USD Dimensions 2.91 in L x 3 in W x 3.12 in H EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 1250.0000 lb Gross Weight per Pack Metric 566.99 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200040 Height 3.5433 in Height [Metric] 8.8900 cm Interrupt Rating 5/10 kA Item Group 00015 Length 4.7244 in Length [Metric] 11.6840 cm Manufacturer Schneider Electric Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401449&lang=en-us Mounting Type Bolt-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 Returnable N Standard UL LISTED-CSA Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedHACR RatedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Stock Status NONSTOCK Sub Brand QO Temperature Rating 104 °F Trip Type Shunt/Thermal Magnetic Type Type QOB Standard UNSPSC 39121603 UPC 11 78590143549 UPC 12 785901435495 Voltage Rating 120/240 VAC/48 VDC Warranty Description Contractual Warranty:18 months Width 3.1496 in Width [Metric] 8.1280 cm Wire Size 8 to 2 AWG HACR rated STANDARD Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button 10 kA at 120/240 VAC, 5 kA at 48 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOB3401042 |
| Amperage Rating | 40 A |
| Application | HACR RATED |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | QOB3401042 |
| Connection | AWG 8...AWG 2 COPPER OR ALUMINIUM,BOX LUGS |
| Connection Type | Box Lug |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 2.91 in L x 3 in W x 3.12 in H |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 1250.0000 lb |
| Gross Weight per Pack Metric | 566.99 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 3.5433 in |
| Height [Metric] | 8.8900 cm |
| Interrupt Rating | 5/10 kA |
| Item Group | 00015 |
| Length | 4.7244 in |
| Length [Metric] | 11.6840 cm |
| Manufacturer | Schneider Electric |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401449&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 |
| Returnable | N |
| Standard | UL LISTED-CSA |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedHACR RatedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Stock Status | NONSTOCK |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Trip Type | Shunt/Thermal Magnetic |
| Type | Type QOB Standard |
| UNSPSC | 39121603 |
| UPC 11 | 78590143549 |
| UPC 12 | 785901435495 |
| Voltage Rating | 120/240 VAC/48 VDC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 3.1496 in |
| Width [Metric] | 8.1280 cm |
| Wire Size | 8 to 2 AWG |
| HACR rated |
| STANDARD |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
| 10 kA at 120/240 VAC, 5 kA at 48 VDC interrupt rating |
