Square D™
Square D™ QOB250SWN Type QOB-SWN Miniature Circuit Breaker, 120/240 VAC, 50 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ QOB250SWN Type QOB-SWN Miniature Circuit Breaker, 120/240 VAC, 50 A, 2 Poles, Thermal Magnetic Trip
SKUPDW~6414085
MFGR #QOB250SWN
Your Cost: $110.53/ea
List: QO circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the ''World's Finest" industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
QO circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the ''World's Finest" industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
Alternate Catalog Number QOB250SWN Amperage Rating 50 A Application Not rated ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number QOB250SWN Connection BOX LUGS #8 TO #2 AWG(AL/CU) Connection Type Box Lug Country of Origin MX Dimensions 3.12 in H x 1.5 in W x 2.91 in D EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.6600 lb Harmonization Tariff Schedule Code 8536200020 Height 3.12 in Interrupt Rating 10 kA at 120/240 VAC/5 kA at 48 VDC Item Group 00015 Length 2.91 in Manufacturer Schneider Electric Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401089&lang=en-us Mounting Type Bolt-On Number Of Poles 2 Operating Temperature 40 °C Phase 1 Returnable Y Standard UL LISTED - CSA CERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Stock Status NONSTOCK Sub Brand QO Temperature Rating 104 °F Trip Type Thermal Magnetic Type Type QOB-SWN UNSPSC 39121603 UPC 11 785901544388 UPC 12 785901544388 Voltage Rating 120/240 VAC Warranty Description Contractual Warranty:18 months Width 1.5 in Wire Size 8 to 2 AWG Al/Cu NOT RATED SWITCH NEUTRAL BOLT-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button Switch neutral common trip
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOB250SWN |
| Amperage Rating | 50 A |
| Application | Not rated |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | QOB250SWN |
| Connection | BOX LUGS #8 TO #2 AWG(AL/CU) |
| Connection Type | Box Lug |
| Country of Origin | MX |
| Dimensions | 3.12 in H x 1.5 in W x 2.91 in D |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.6600 lb |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 3.12 in |
| Interrupt Rating | 10 kA at 120/240 VAC/5 kA at 48 VDC |
| Item Group | 00015 |
| Length | 2.91 in |
| Manufacturer | Schneider Electric |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=401089&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Stock Status | NONSTOCK |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Trip Type | Thermal Magnetic |
| Type | Type QOB-SWN |
| UNSPSC | 39121603 |
| UPC 11 | 785901544388 |
| UPC 12 | 785901544388 |
| Voltage Rating | 120/240 VAC |
| Warranty Description | Contractual Warranty:18 months |
| Width | 1.5 in |
| Wire Size | 8 to 2 AWG Al/Cu |
| NOT RATED |
| SWITCH NEUTRAL BOLT-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
| Switch neutral common trip |
