Square D™
Square D™ QOB115HID Type QOB-HID Miniature Circuit Breaker, 120/240 VAC, 15 A, 1 Pole, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ QOB115HID Type QOB-HID Miniature Circuit Breaker, 120/240 VAC, 15 A, 1 Pole, Thermal Magnetic Trip
SKU791722
MFGR #QOB115HID
Your Cost: $54.58/ea
Square D QOB115HID MINIATURE CIRCUIT BREAKER 120/240V 15A,1-Phase,10kA,120/240 Vac,15A,1P,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,High Intensity Discharge Bolt-On,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),Provides overload and short circuit protection Designed for use on circuits feeding fluorescent and other high intensity discharge lighting systems.,QO,UL Listed - CSA Certified
Square D QOB115HID MINIATURE CIRCUIT BREAKER 120/240V 15A,1-Phase,10kA,120/240 Vac,15A,1P,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,High Intensity Discharge Bolt-On,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),Provides overload and short circuit protection Designed for use on circuits feeding fluorescent and other high intensity discharge lighting systems.,QO,UL Listed - CSA Certified
Alternate Catalog Number QOB115HID Amperage Rating 15 A Application SWITCHING DUTY RATED ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number QOB115HID Connection Pressure Plate Connection Type Pressure Plate Country of Origin MX Dimensions 3 in H x 0.75 in W x 2.91 in D EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.3100 lb Gross Weight per Pack Metric 140.61 Gross Weight UOM Metric g Height 3.37 in Height [Metric] 8.6360 cm Interrupt Rating 10 kA at 120/240 VAC/5 kA at 48 VDC Item Group 00015 Length 3.27 in Length [Metric] 8.3820 cm Manufacturer Schneider Electric Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=400285&lang=en-us Mounting Type Bolt-On Number Of Poles 1 Operating Temperature 40 °C Phase 1 Returnable Y Standard UL LISTED - CSA CERTIFIED Stock Status NONSTOCK Sub Brand QO Temperature Rating 104 °F Trip Type Thermal Magnetic Type Type QOB-HID UNSPSC 39121603 UPC 11 78590154388 UPC 12 785901543886 Voltage Rating 120/240 VAC Warranty Description Contractual Warranty: 18 months Width 0.79 in Width [Metric] 2.0320 cm Wire Size 14 to 8 AWG Al/Cu Switching Duty rated HIGH INTENSITY DISCHARGE BOLT-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button High intensity discharge rated
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QOB115HID |
| Amperage Rating | 15 A |
| Application | SWITCHING DUTY RATED |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | QOB115HID |
| Connection | Pressure Plate |
| Connection Type | Pressure Plate |
| Country of Origin | MX |
| Dimensions | 3 in H x 0.75 in W x 2.91 in D |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.3100 lb |
| Gross Weight per Pack Metric | 140.61 |
| Gross Weight UOM Metric | g |
| Height | 3.37 in |
| Height [Metric] | 8.6360 cm |
| Interrupt Rating | 10 kA at 120/240 VAC/5 kA at 48 VDC |
| Item Group | 00015 |
| Length | 3.27 in |
| Length [Metric] | 8.3820 cm |
| Manufacturer | Schneider Electric |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=400285&lang=en-us |
| Mounting Type | Bolt-On |
| Number Of Poles | 1 |
| Operating Temperature | 40 °C |
| Phase | 1 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Stock Status | NONSTOCK |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Trip Type | Thermal Magnetic |
| Type | Type QOB-HID |
| UNSPSC | 39121603 |
| UPC 11 | 78590154388 |
| UPC 12 | 785901543886 |
| Voltage Rating | 120/240 VAC |
| Warranty Description | Contractual Warranty: 18 months |
| Width | 0.79 in |
| Width [Metric] | 2.0320 cm |
| Wire Size | 14 to 8 AWG Al/Cu |
| Switching Duty rated |
| HIGH INTENSITY DISCHARGE BOLT-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
| High intensity discharge rated |
