Square D™ QO3705273 Type QO Miniature Circuit Breaker, 120/240 VAC, 70 A, 10 kA at 120/240 VAC Interrupt, 3 Poles, Thermal/Magnetic Trip
Custom_Product_Images_Illustration
Square D™ QO3705273 Type QO Miniature Circuit Breaker, 120/240 VAC, 70 A, 10 kA at 120/240 VAC Interrupt, 3 Poles, Thermal/Magnetic Trip
SKUPDW~6415352
MFGR #QO3705273
Price Not Available
List: Square D™ Miniature Circuit Breaker, Type QO, 120/240 VAC, 70 A, 50/60 Hz Frequency, 10 kA at 120/240 VAC Interrupt, Thermal/Magnetic Trip, 3 Pole, 3 ph, Ring Tongue Connection, 8 to 2 AWG Cu Wire, NEMA AB1 Enclosure, Plug-In Mounting, 104 deg F, 3.12 in H x 2.25 in W x 2.91 in D Dimensions, Fiberglass Filled Thermoset
Square D™ Miniature Circuit Breaker, Type QO, 120/240 VAC, 70 A, 50/60 Hz Frequency, 10 kA at 120/240 VAC Interrupt, Thermal/Magnetic Trip, 3 Pole, 3 ph, Ring Tongue Connection, 8 to 2 AWG Cu Wire, NEMA AB1 Enclosure, Plug-In Mounting, 104 deg F, 3.12 in H x 2.25 in W x 2.91 in D Dimensions, Fiberglass Filled Thermoset
Alternate Catalog Number QO3705273 Application HACR rated ARRA Compliant N Buy American Compliant N Catalog Number QO3705273 Connection Ring tongue;AWG 8...AWG 2 copper Connection Type Ring Tongue Country of Origin US Currency USD Dimensions 3.12 in H x 2.25 in W x 2.91 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frequency Rating 50/60 Gross Weight Per Pack 5.0349 lb Gross Weight per Pack Metric 503.49 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 5.8420 in Height [Metric] 5.8420 cm Item Group 00012 Length 9.6520 in Length [Metric] 9.6520 cm Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=400103&lang=en-us Mounting Type Plug-In Number Of Poles 3 Operating Temperature 40 A°C Phase 3 Returnable N Standard UL LISTED-CSA Sub Brand QO Temperature Rating 104 Type Type QO UNSPSC 39121603 UPC 11 78590160863 UPC 12 785901608639 Warranty Description Contractual Warranty:18 months Width 8.6360 in Width [Metric] 8.6360 cm Wire Size 8 to 2 AWG Cu Brand Square D™ Manufacturer Schneider Electric Amperage Rating 70 A Interrupt Rating 10 kA at 120/240 VAC kA Trip Type Thermal Magnetic Voltage Rating 120/240 HACR rated STANDARD
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QO3705273 |
| Application | HACR rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QO3705273 |
| Connection | Ring tongue;AWG 8...AWG 2 copper |
| Connection Type | Ring Tongue |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 3.12 in H x 2.25 in W x 2.91 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 5.0349 lb |
| Gross Weight per Pack Metric | 503.49 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 5.8420 in |
| Height [Metric] | 5.8420 cm |
| Item Group | 00012 |
| Length | 9.6520 in |
| Length [Metric] | 9.6520 cm |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=400103&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 3 |
| Operating Temperature | 40 A°C |
| Phase | 3 |
| Returnable | N |
| Standard | UL LISTED-CSA |
| Sub Brand | QO |
| Temperature Rating | 104 |
| Type | Type QO |
| UNSPSC | 39121603 |
| UPC 11 | 78590160863 |
| UPC 12 | 785901608639 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 8.6360 in |
| Width [Metric] | 8.6360 cm |
| Wire Size | 8 to 2 AWG Cu |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 70 A |
| Interrupt Rating | 10 kA at 120/240 VAC kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 120/240 |
| HACR rated |
| STANDARD |
