Square D™ QO250HID Type QO-HID Miniature Circuit Breaker, 120/240 VAC/48 VDC, 50 A, 2 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ QO250HID Type QO-HID Miniature Circuit Breaker, 120/240 VAC/48 VDC, 50 A, 2 Poles, Thermal Magnetic Trip
SKU290140
MFGR #QO250HID
Square D QO250HID MINIATURE CIRCUIT BREAKER 120/240V 50A,1-Phase,10kA,120/240 Vac,2P,50A,Box Lugs #8 to #2 AWG(Al/Cu),Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,High Intensity Discharge Plug-On,Miniature Circuit Breaker,Provides overload and short circuit protection Designed for use on circuits feeding fluorescent and other high intensity discharge lighting systems.,QO,UL Listed - CSA Certified
Square D QO250HID MINIATURE CIRCUIT BREAKER 120/240V 50A,1-Phase,10kA,120/240 Vac,2P,50A,Box Lugs #8 to #2 AWG(Al/Cu),Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,High Intensity Discharge Plug-On,Miniature Circuit Breaker,Provides overload and short circuit protection Designed for use on circuits feeding fluorescent and other high intensity discharge lighting systems.,QO,UL Listed - CSA Certified
Amperage Rating 50 A Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION DESIGNED FOR USE ON CIRCUITS FEEDING FLUORESCENT AND OTHER HIGH INTENSITY DISCHARGE LIGHTING SYSTEMS. ARRA Compliant N Brand Square D™ Buy American Compliant N Catalog Number QO250HID Connection BOX LUGS #8 TO #2 AWG(AL/CU) Connection Type Box Lug Country of Origin MX Dimensions 2.91 in L x 1.5 in W x 3.12 in H EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.6200 lb Harmonization Tariff Schedule Code 8536200020 Height 3.12 in Interrupt Rating 10 kA Item Group 00080 Length 2.91 in Manufacturer Schneider Electric Material Fiberglass Filled Thermoset Mounting Type Plug-In Number Of Poles 2 Operating Temperature 40 °C Phase 1 Returnable Y Standard UL LISTED - CSA CERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Stock Status NONSTOCK Sub Brand QO Temperature Rating 104 °F Trip Type Thermal Magnetic Type Type QO UNSPSC 39121603 UPC 11 78590154382 UPC 12 785901543824 Voltage Rating 120/240 VAC Width 1.5 in Wire Size 8 to 2 AWG PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION DESIGNED FOR USE ON CIRCUITS FEEDING FLUORESCENT AND OTHER HIGH INTENSITY DISCHARGE LIGHTING SYSTEMS. HIGH INTENSITY DISCHARGE PLUG-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button High intensity discharge rated
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Amperage Rating | 50 A |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION DESIGNED FOR USE ON CIRCUITS FEEDING FLUORESCENT AND OTHER HIGH INTENSITY DISCHARGE LIGHTING SYSTEMS. |
| ARRA Compliant | N |
| Brand | Square D™ |
| Buy American Compliant | N |
| Catalog Number | QO250HID |
| Connection | BOX LUGS #8 TO #2 AWG(AL/CU) |
| Connection Type | Box Lug |
| Country of Origin | MX |
| Dimensions | 2.91 in L x 1.5 in W x 3.12 in H |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.6200 lb |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 3.12 in |
| Interrupt Rating | 10 kA |
| Item Group | 00080 |
| Length | 2.91 in |
| Manufacturer | Schneider Electric |
| Material | Fiberglass Filled Thermoset |
| Mounting Type | Plug-In |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489 File No. E84967CSA C22.2 No. 5NEMA AB1Federal Specification W-C-375B/GENNOM/ANCE CertifiedPROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Stock Status | NONSTOCK |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Trip Type | Thermal Magnetic |
| Type | Type QO |
| UNSPSC | 39121603 |
| UPC 11 | 78590154382 |
| UPC 12 | 785901543824 |
| Voltage Rating | 120/240 VAC |
| Width | 1.5 in |
| Wire Size | 8 to 2 AWG |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION DESIGNED FOR USE ON CIRCUITS FEEDING FLUORESCENT AND OTHER HIGH INTENSITY DISCHARGE LIGHTING SYSTEMS. |
| HIGH INTENSITY DISCHARGE PLUG-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
| High intensity discharge rated |
