Square D™ QO1205237 Type QO Miniature Circuit Breaker, 120/240 VAC, 48 VDC, 20 A, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, 1 Poles, Thermal/Magnetic Trip
Custom_Product_Images_Illustration
Square D™ QO1205237 Type QO Miniature Circuit Breaker, 120/240 VAC, 48 VDC, 20 A, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, 1 Poles, Thermal/Magnetic Trip
SKUPDW~6414918
MFGR #QO1205237
Your Cost: $20.48/ea
List: Square D™ Miniature Circuit Breaker, Type QO, 120/240 VAC, 48 VDC, 20 A, 50/60 Hz Frequency, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, Thermal/Magnetic Trip, 1 Pole, 1 ph, Ring Tongue Connection, 14 to 8 AWG Al/Cu Wire, NEMA AB1 Enclosure, Plug-In Mounting, 104 deg F, 3 in H x 0.75 in W x 2.91 in D Dimensions, Fiberglass Filled Thermoset
Square D™ Miniature Circuit Breaker, Type QO, 120/240 VAC, 48 VDC, 20 A, 50/60 Hz Frequency, 10 kA at 120/240 VAC, 5 kA at 48 VDC Interrupt, Thermal/Magnetic Trip, 1 Pole, 1 ph, Ring Tongue Connection, 14 to 8 AWG Al/Cu Wire, NEMA AB1 Enclosure, Plug-In Mounting, 104 deg F, 3 in H x 0.75 in W x 2.91 in D Dimensions, Fiberglass Filled Thermoset
Alternate Catalog Number QO1205237 Application HACR and Switching Duty rated ARRA Compliant N Buy American Compliant N Catalog Number QO1205237 Connection AWG 14...AWG 8 COPPER OR ALUMINIUM,RING TONGUE Connection Type Ring Tongue Country of Origin MX Currency USD Dimensions 3 in H x 0.75 in W x 2.91 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frequency Rating 50/60 Gross Volume Per Pack 5.95 Gross Volume per Pack Metric 97.50 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 1.3608 lb Gross Weight per Pack Metric 136.08 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 1.2700 in Height [Metric] 1.2700 cm Item Group 00004 Length 8.6360 in Length [Metric] 8.6360 cm Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398417&lang=en-us Mounting Type Plug-In Number Of Poles 1 Operating Temperature 40 A°C Phase 1 Returnable N Standard UL LISTED-CSA Sub Brand QO Temperature Rating 104 Type Type QO UNSPSC 39121603 UPC 11 78590149554 UPC 12 785901495543 Warranty Description Contractual Warranty:18 months Width 8.8900 in Width [Metric] 8.8900 cm Wire Size 14 to 8 AWG Al/Cu Brand Square D™ Manufacturer Schneider Electric Amperage Rating 20 A Interrupt Rating 10 kA at 120/240 VAC, 5 kA at 48 VDC Trip Type Thermal Magnetic Voltage Rating 120/240 VAC, 48 VDC HACR AND SWITCHING DUTY RATED STANDARD
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QO1205237 |
| Application | HACR and Switching Duty rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QO1205237 |
| Connection | AWG 14...AWG 8 COPPER OR ALUMINIUM,RING TONGUE |
| Connection Type | Ring Tongue |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 3 in H x 0.75 in W x 2.91 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 |
| Gross Volume Per Pack | 5.95 |
| Gross Volume per Pack Metric | 97.50 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 1.3608 lb |
| Gross Weight per Pack Metric | 136.08 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 1.2700 in |
| Height [Metric] | 1.2700 cm |
| Item Group | 00004 |
| Length | 8.6360 in |
| Length [Metric] | 8.6360 cm |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398417&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 1 |
| Operating Temperature | 40 A°C |
| Phase | 1 |
| Returnable | N |
| Standard | UL LISTED-CSA |
| Sub Brand | QO |
| Temperature Rating | 104 |
| Type | Type QO |
| UNSPSC | 39121603 |
| UPC 11 | 78590149554 |
| UPC 12 | 785901495543 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 8.8900 in |
| Width [Metric] | 8.8900 cm |
| Wire Size | 14 to 8 AWG Al/Cu |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 20 A |
| Interrupt Rating | 10 kA at 120/240 VAC, 5 kA at 48 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 120/240 VAC, 48 VDC |
| HACR AND SWITCHING DUTY RATED |
| STANDARD |
