Square D™
Square D™ QJL22150 Type QJ Molded Case Circuit Breaker, 240 VAC, 150 A, 100 kA Interrupt, 2 Poles, Thermal/Magnetic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ QJL22150 Type QJ Molded Case Circuit Breaker, 240 VAC, 150 A, 100 kA Interrupt, 2 Poles, Thermal/Magnetic Trip
SKUPDW~6413627
MFGR #QJL22150
Your Cost: $2,959.84/ea
List: Square D™ PowerPact™ Molded Case Circuit Breaker, Type QJ, 240 VAC, 150 A, 50/60 Hz Frequency, 100 kA Interrupt, Q Frame, Thermal/Magnetic Trip, 1200 to 2400 A Trip, 2 Pole, 1 ph, Toggle Actuator, Line/Load Lugs Connection, 4 AWG to 300 kcmil Al/Cu Wire, NEMA AB1-1999 Enclosure, Unit Mounting, 104 deg F, 6.47 in H x 3 in W x 3.93 in D Dimensions
Square D™ PowerPact™ Molded Case Circuit Breaker, Type QJ, 240 VAC, 150 A, 50/60 Hz Frequency, 100 kA Interrupt, Q Frame, Thermal/Magnetic Trip, 1200 to 2400 A Trip, 2 Pole, 1 ph, Toggle Actuator, Line/Load Lugs Connection, 4 AWG to 300 kcmil Al/Cu Wire, NEMA AB1-1999 Enclosure, Unit Mounting, 104 deg F, 6.47 in H x 3 in W x 3.93 in D Dimensions
Actuator Type Toggle Alternate Catalog Number QJL22150 ARRA Compliant N Buy American Compliant N Catalog Number QJL22150 Connection LUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-LUGS LINE AWG 4...300 KCMIL ALUMINIUM/COPPER Connection Type Line/Load Lugs Country of Origin MX Currency USD Dimensions 6.47 in H x 3 in W x 3.93 in D Enclosure Type NEMA AB1-1999 EU RoHS Indicator Y Frame Q Series Frequency Rating 50/60 Gross Weight Per Pack 0.0152 lb Gross Weight per Pack Metric 1.52 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 14.1270 in Height [Metric] 14.1270 cm Item Group 00005 Length 24.7650 in Length [Metric] 24.7650 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=436249&lang=en-us Mounting Type Unit Number Of Poles 2 Phase 1 Returnable Y Standard CSA-IEC-UL LISTED Sub Brand POWERPACT Substitute Product Catalog Number QBPA Temperature Rating 104 Trip Range 1200 to 2400 Type Type QJ UNSPSC 39121601 UPC 11 78590187761 UPC 12 785901877615 Warranty Description Contractual Warranty:18 months Width 14.7570 in Width [Metric] 14.7570 cm Wire Size 4 AWG to 300 kcmil Al/Cu Brand Square D™ Manufacturer Schneider Electric Amperage Rating 150 A Interrupt Rating 100 Trip Type Thermal Magnetic Voltage Rating 240 VAC UNIT MOUNT
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | QJL22150 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QJL22150 |
| Connection | LUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-LUGS LINE AWG 4...300 KCMIL ALUMINIUM/COPPER |
| Connection Type | Line/Load Lugs |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 6.47 in H x 3 in W x 3.93 in D |
| Enclosure Type | NEMA AB1-1999 |
| EU RoHS Indicator | Y |
| Frame | Q Series |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 0.0152 lb |
| Gross Weight per Pack Metric | 1.52 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 14.1270 in |
| Height [Metric] | 14.1270 cm |
| Item Group | 00005 |
| Length | 24.7650 in |
| Length [Metric] | 24.7650 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=436249&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 2 |
| Phase | 1 |
| Returnable | Y |
| Standard | CSA-IEC-UL LISTED |
| Sub Brand | POWERPACT |
| Substitute Product Catalog Number | QBPA |
| Temperature Rating | 104 |
| Trip Range | 1200 to 2400 |
| Type | Type QJ |
| UNSPSC | 39121601 |
| UPC 11 | 78590187761 |
| UPC 12 | 785901877615 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 14.7570 in |
| Width [Metric] | 14.7570 cm |
| Wire Size | 4 AWG to 300 kcmil Al/Cu |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 150 A |
| Interrupt Rating | 100 |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| UNIT MOUNT |
