Square D™ QH130 Type QH Miniature Circuit Breaker, 120/240 VAC, 30 A, 65 kA at 120/240 VAC Interrupt, 1 Pole
Custom_Product_Images_Illustration
Square D™ QH130 Type QH Miniature Circuit Breaker, 120/240 VAC, 30 A, 65 kA at 120/240 VAC Interrupt, 1 Pole
SKU95560
MFGR #QH130
Your Cost: $54.72/ea
List: Square D QH130 MINIATURE CIRCUIT BREAKER 120/240V 30A,120/240 Vac,1P,30A,65kA,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,HACR rated,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),QO,QO loadcenter, NQ, NQO, NQOD, OEM mounting bases, and Speed-D(R) switchboard,Standard Plug-On,Thermal Magnetic Breaker,UL Listed - CSA Certified
Square D QH130 MINIATURE CIRCUIT BREAKER 120/240V 30A,120/240 Vac,1P,30A,65kA,Calibrated for use at 40 degrees C. See Data Bulletin 0100DB0101 for re-rating information.,Fiberglass filled thermoset molding material.,HACR rated,Miniature Circuit Breaker,Pressure Plate #14 to #8 AWG(Al/Cu),QO,QO loadcenter, NQ, NQO, NQOD, OEM mounting bases, and Speed-D(R) switchboard,Standard Plug-On,Thermal Magnetic Breaker,UL Listed - CSA Certified
Alternate Catalog Number QH130 Application HACR rated ARRA Compliant N Buy American Compliant N Catalog Number QH130 Connection Pressure Plate Connection Type Pressure Plate Country of Origin MX Currency USD Dimensions 2.91 in L x 0.75 in W x 3 in H Enclosure QO LOADCENTER, NQ, NQO, NQOD, OEM MOUNTING BASES, AND SPEED-D?® SWITCHBOARD Enclosure Type NEMA AB1 EU RoHS Indicator Y Frequency Rating 50/60 Hz Gross Weight Per Pack 0.3100 lb Gross Weight per Pack Metric 140.61 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 2.0320 in Height [Metric] 2.0320 cm Item Group 00926 Length 8.3820 in Length [Metric] 8.3820 cm Material Fiberglass Filled Thermoset Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398185&lang=en-us Mounting Type Plug-In Number Of Poles 1 Operating Temperature 40 °C Phase 1 Returnable Y Standard UL LISTED - CSA CERTIFIED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5Federal Specification W-C-375B/GENHACR RatedNOM-ANCE CertifiedUL 489 File No. E84967PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Sub Brand QO Temperature Rating 104 °F Type Type QH Standard UNSPSC 39121603 UPC 11 78590101289 UPC 12 785901012894 Warranty Description Contractual Warranty:18 months Width 7.6200 in Width [Metric] 7.6200 cm Wire Size 14 to 8 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 30 A Interrupt Rating 65 kA Trip Type Thermal Magnetic Voltage Rating 120/240 VAC HACR rated STANDARD PLUG-ON Designed for superior safety, quality and reliability Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection Saves space compact 3/4 in W design for small system footprint Faster installation fewer connections Frees gutter space no pigtails with the innovative plug-on neutral design Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | QH130 |
| Application | HACR rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QH130 |
| Connection | Pressure Plate |
| Connection Type | Pressure Plate |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 2.91 in L x 0.75 in W x 3 in H |
| Enclosure | QO LOADCENTER, NQ, NQO, NQOD, OEM MOUNTING BASES, AND SPEED-D?® SWITCHBOARD |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.3100 lb |
| Gross Weight per Pack Metric | 140.61 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 2.0320 in |
| Height [Metric] | 2.0320 cm |
| Item Group | 00926 |
| Length | 8.3820 in |
| Length [Metric] | 8.3820 cm |
| Material | Fiberglass Filled Thermoset |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=398185&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 1 |
| Operating Temperature | 40 °C |
| Phase | 1 |
| Returnable | Y |
| Standard | UL LISTED - CSA CERTIFIED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantCSA 22.2 No. 5Federal Specification W-C-375B/GENHACR RatedNOM-ANCE CertifiedUL 489 File No. E84967PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Sub Brand | QO |
| Temperature Rating | 104 °F |
| Type | Type QH Standard |
| UNSPSC | 39121603 |
| UPC 11 | 78590101289 |
| UPC 12 | 785901012894 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 7.6200 in |
| Width [Metric] | 7.6200 cm |
| Wire Size | 14 to 8 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 30 A |
| Interrupt Rating | 65 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 120/240 VAC |
| HACR rated |
| STANDARD PLUG-ON |
| Designed for superior safety, quality and reliability |
| Engineered with the quality and craftsmanship that have made Square D™ the preferred brand of electrician and homeowners |
| First and only offer in the market to put the game changing Visi-Trip™ on all the circuit breakers for easy trip detection |
| Saves space compact 3/4 in W design for small system footprint |
| Faster installation fewer connections |
| Frees gutter space no pigtails with the innovative plug-on neutral design |
| Easier troubleshooting time saver diagnostics provide additional circuit information at the touch of a button |
