Square D™
Square D™ PowerPact™ QGL22080 Type QG Molded Case Circuit Breaker, 240 VAC, 80 A, 65 kA Interrupt, 2 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ PowerPact™ QGL22080 Type QG Molded Case Circuit Breaker, 240 VAC, 80 A, 65 kA Interrupt, 2 Poles
SKU633472
MFGR #QGL22080
Your Cost: $2,395.57/ea
List: Square D QGL22080 MOLDED CASE CIRCUIT BREAKER 240V 80A,1000 A,1800 A,80 A,2-Pole,240 V AC,240 V AC,65 kA 240 V AC,80 A,G,Line Lug - Load Lug,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,unit mount
Square D QGL22080 MOLDED CASE CIRCUIT BREAKER 240V 80A,1000 A,1800 A,80 A,2-Pole,240 V AC,240 V AC,65 kA 240 V AC,80 A,G,Line Lug - Load Lug,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,unit mount
Actuator Type Toggle Alternate Catalog Number QGL22080 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number QGL22080 Connection LUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-LUGS LINE AWG 4...300 KCMIL ALUMINIUM/COPPER Connection Type Line/Load Lugs Country of Origin MX Currency USD Dimensions 6.47 in H x 3 in W x 3.93 in D EU RoHS Indicator Y Frame Q Series Frequency Rating 50/60 Hz Gross Weight Per Pack 3.3300 lb Gross Weight per Pack Metric 1.51 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 14.1270 in Height [Metric] 14.1270 cm Item Group 00005 Length 24.7650 in Length [Metric] 24.7650 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=435969&lang=en-us Mounting Type Unit Number Of Poles 2 Phase 1 pH Returnable Y Standard CSA-IEC-UL LISTED Standards ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No. 5-02IEC 60947-2PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov Sub Brand POWERPACT Substitute Product Catalog Number QBPA Temperature Rating 104 °F Trip Range 1000 to 1800 A Type Type QG UNSPSC 39121601 UPC 11 78590146195 UPC 12 785901461951 Warranty Description Contractual Warranty:18 months Width 14.7570 in Width [Metric] 14.7570 cm Wire Size 4 AWG to 300 kcmil Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 80 A Interrupt Rating 65 kA Trip Type Thermal Magnetic Voltage Rating 240 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION UNIT MOUNT Field installable handle padlock attachment available for locking in ON or OFF position and may be used with available mechanical interlocks
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | QGL22080 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | QGL22080 |
| Connection | LUGS LOAD AWG 4...300 KCMIL ALUMINIUM/COPPER-LUGS LINE AWG 4...300 KCMIL ALUMINIUM/COPPER |
| Connection Type | Line/Load Lugs |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 6.47 in H x 3 in W x 3.93 in D |
| EU RoHS Indicator | Y |
| Frame | Q Series |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.3300 lb |
| Gross Weight per Pack Metric | 1.51 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 14.1270 in |
| Height [Metric] | 14.1270 cm |
| Item Group | 00005 |
| Length | 24.7650 in |
| Length [Metric] | 24.7650 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=435969&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 2 |
| Phase | 1 pH |
| Returnable | Y |
| Standard | CSA-IEC-UL LISTED |
| Standards | ARRA CompliantBuy American Act CompliantRoHS CompliantUL 489CSA C22.2 No. 5-02IEC 60947-2PROP65: Cancer and Reproductive Harm - www.p65Warnings.ca.gov |
| Sub Brand | POWERPACT |
| Substitute Product Catalog Number | QBPA |
| Temperature Rating | 104 °F |
| Trip Range | 1000 to 1800 A |
| Type | Type QG |
| UNSPSC | 39121601 |
| UPC 11 | 78590146195 |
| UPC 12 | 785901461951 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 14.7570 in |
| Width [Metric] | 14.7570 cm |
| Wire Size | 4 AWG to 300 kcmil Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 80 A |
| Interrupt Rating | 65 kA |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 240 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Field installable handle padlock attachment available for locking in ON or OFF position and may be used with available mechanical interlocks |
