Square D™ PowerPact™ MGL36500SA 80% Rated M Molded Case Circuit Breaker, 600 VAC, 500 A, 18 kA Interrupt, 3 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
Custom_Product_Images_Illustration
Square D™ PowerPact™ MGL36500SA 80% Rated M Molded Case Circuit Breaker, 600 VAC, 500 A, 18 kA Interrupt, 3 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
SKU1364178
MFGR #MGL36500SA
Your Cost: $7,210.30/ea
List: Square D™ PowerPact™ M Molded Case Circuit Breaker, 80% Rated, 600 VAC, 500 A, 50/60 Hz, 18 kA Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 3 Pole, 3, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Wire, DIN Rail/Unit Mount, -13 to 158 deg F, 12.86 in H x 8.27 in W x 8.07 in D
Square D™ PowerPact™ M Molded Case Circuit Breaker, 80% Rated, 600 VAC, 500 A, 50/60 Hz, 18 kA Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 3 Pole, 3, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Wire, DIN Rail/Unit Mount, -13 to 158 deg F, 12.86 in H x 8.27 in W x 8.07 in D
Actuator Type Manual Alternate Catalog Number MGL36500SA Application Construction, Commercial Buildings, Control, Monitoring, Oil, Gas, Marine, Industrial Buildings, Water Wastewater, Healthcare Facilities, Data Centers and Educational Campuses ARRA Compliant N Buy American Compliant N Catalog Number MGL36500SA Connection Lugs load;lugs line; 3 x AWG 3/0...3 x 500 kcmil aluminium/copper Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 12.86 in H x 8.27 in W x 8.07 in D EU RoHS Indicator Y Frame M Frequency Rating 50/60 Gross Weight Per Pack 28.9900 lb Gross Weight per Pack Metric 13.15 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 9.8425 in Height [Metric] 25.4000 cm Item Group 01205 Length 17.7165 in Length [Metric] 45.2450 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430903&lang=en-us Mounting Type DIN Rail/Unit Number Of Poles 3 Phase 3 Returnable Y Standard CSA-UL LISTED-IEC Temperature Rating -13 to 158 Type 80% Rated UNSPSC 39121601 UPC 11 78590146094 UPC 12 785901460947 Warranty Description Contractual Warranty:18 months Width 11.8110 in Width [Metric] 29.8450 cm Wire Size 3/0 AWG to 500 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 500 Interrupt Rating 18 Trip Type Electronic Basic ET 1.0 LI/Non-Interchangeable Voltage Rating 600 VAC Construction, Commercial Buildings, Control, Monitoring, Oil, Gas, Marine, Industrial Buildings, Water Wastewater, Healthcare Facilities, Data Centers and Educational Campuses Shunt trip 110...130 V AC/DC A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility 600 VAC, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Manual |
| Alternate Catalog Number | MGL36500SA |
| Application | Construction, Commercial Buildings, Control, Monitoring, Oil, Gas, Marine, Industrial Buildings, Water Wastewater, Healthcare Facilities, Data Centers and Educational Campuses |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MGL36500SA |
| Connection | Lugs load;lugs line; 3 x AWG 3/0...3 x 500 kcmil aluminium/copper |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 12.86 in H x 8.27 in W x 8.07 in D |
| EU RoHS Indicator | Y |
| Frame | M |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 28.9900 lb |
| Gross Weight per Pack Metric | 13.15 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 9.8425 in |
| Height [Metric] | 25.4000 cm |
| Item Group | 01205 |
| Length | 17.7165 in |
| Length [Metric] | 45.2450 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430903&lang=en-us |
| Mounting Type | DIN Rail/Unit |
| Number Of Poles | 3 |
| Phase | 3 |
| Returnable | Y |
| Standard | CSA-UL LISTED-IEC |
| Temperature Rating | -13 to 158 |
| Type | 80% Rated |
| UNSPSC | 39121601 |
| UPC 11 | 78590146094 |
| UPC 12 | 785901460947 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 11.8110 in |
| Width [Metric] | 29.8450 cm |
| Wire Size | 3/0 AWG to 500 kcmil |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 500 |
| Interrupt Rating | 18 |
| Trip Type | Electronic Basic ET 1.0 LI/Non-Interchangeable |
| Voltage Rating | 600 VAC |
| Construction, Commercial Buildings, Control, Monitoring, Oil, Gas, Marine, Industrial Buildings, Water Wastewater, Healthcare Facilities, Data Centers and Educational Campuses |
| Shunt trip 110...130 V AC/DC |
| A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility |
| 600 VAC, 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC interrupt rating |
