Square D™
Square D™ PowerPact™ MGA Molded Case Circuit Breaker, 600 VAC, 400 A, 18 kA Interrupt, 3 Poles, Electronic Trip
Custom_Product_Images_Illustration
Square D™
Square D™ PowerPact™ MGA Molded Case Circuit Breaker, 600 VAC, 400 A, 18 kA Interrupt, 3 Poles, Electronic Trip
SKU384342
MFGR #MGA36400
Your Cost: $5,205.88/ea
List: Square D MGA36400 MOLDED CASE CIRCUIT BREAKER 600V 400A,12.80 in.,3-Phase,3P,400A,400A,40deg Celsius,50/60Hz,600 Vac,65kA240Vac - 35kA480Vac - 18kA600Vac,8.10 in.,8.30 in.,Ambient environment,Basic (ET1.0) Fixed Long-Time Adjustable Instantaneous Trip,Electronic,Electronic Trip Circuit Breaker,I-Line Connection (ON end) - Lugs (OFF end) ABC,I-Line Plug-On,M-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,Various
Square D MGA36400 MOLDED CASE CIRCUIT BREAKER 600V 400A,12.80 in.,3-Phase,3P,400A,400A,40deg Celsius,50/60Hz,600 Vac,65kA240Vac - 35kA480Vac - 18kA600Vac,8.10 in.,8.30 in.,Ambient environment,Basic (ET1.0) Fixed Long-Time Adjustable Instantaneous Trip,Electronic,Electronic Trip Circuit Breaker,I-Line Connection (ON end) - Lugs (OFF end) ABC,I-Line Plug-On,M-Frame,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,Various
Actuator ELECTRONIC Actuator Type Electrical Alternate Catalog Number MGA36400 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number MGA36400 Connection I-LINE CONNECTION (ON END) - LUGS (OFF END) ABC Connection Type I-Line™ Lug Country of Origin US Currency USD Dimensions 8.1 in L x 8.3 in W x 12.8 in H Environmental Conditions AMBIENT ENVIRONMENT EU RoHS Indicator Y Frame M Frequency Rating 50/60 Hz Gross Weight Per Pack 28.9900 lb Gross Weight per Pack Metric 13.15 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 26.6700 in Height [Metric] 26.6700 cm Item Group 01200 Length 46.4820 in Length [Metric] 46.4820 cm Material Various Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430831&lang=en-us Mounting Type Plug-On Number Of Poles 3 Operating Temperature 40 °C Phase 3 pH Returnable Y Series MGA Standard UL LISTED - CSA CERTIFIED - IEC RATED Sub Brand POWERPACT Temperature Rating 40 °C Trip Range 400 A Type ELECTRONIC TRIP CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590149614 UPC 12 785901496144 Warranty Description Contractual Warranty:18 months Width 29.9720 in Width [Metric] 29.9720 cm Wire Size 3/0 AWG to 500 kcmil Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 400 A Interrupt Rating 18 kA Trip Type Electronic Basic ET1.0 Fixed Long Time/Adjustable Instantaneous Voltage Rating 600 VAC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION I-LINE PLUG-ON
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | ELECTRONIC |
| Actuator Type | Electrical |
| Alternate Catalog Number | MGA36400 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MGA36400 |
| Connection | I-LINE CONNECTION (ON END) - LUGS (OFF END) ABC |
| Connection Type | I-Line™ Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 8.1 in L x 8.3 in W x 12.8 in H |
| Environmental Conditions | AMBIENT ENVIRONMENT |
| EU RoHS Indicator | Y |
| Frame | M |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 28.9900 lb |
| Gross Weight per Pack Metric | 13.15 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 26.6700 in |
| Height [Metric] | 26.6700 cm |
| Item Group | 01200 |
| Length | 46.4820 in |
| Length [Metric] | 46.4820 cm |
| Material | Various |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430831&lang=en-us |
| Mounting Type | Plug-On |
| Number Of Poles | 3 |
| Operating Temperature | 40 °C |
| Phase | 3 pH |
| Returnable | Y |
| Series | MGA |
| Standard | UL LISTED - CSA CERTIFIED - IEC RATED |
| Sub Brand | POWERPACT |
| Temperature Rating | 40 °C |
| Trip Range | 400 A |
| Type | ELECTRONIC TRIP CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590149614 |
| UPC 12 | 785901496144 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 29.9720 in |
| Width [Metric] | 29.9720 cm |
| Wire Size | 3/0 AWG to 500 kcmil |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 400 A |
| Interrupt Rating | 18 kA |
| Trip Type | Electronic Basic ET1.0 Fixed Long Time/Adjustable Instantaneous |
| Voltage Rating | 600 VAC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| I-LINE PLUG-ON |
