Square D™ PowerPact™ JJL36250C Type JJL Molded Case Circuit Breaker, 600 VAC/250 VDC, 250 A, 3 Poles
Molded Case Circuit Breakers
678813
MFG #: JJL36250C
Square D™
7531.14000
/ ea
Square D JJL36250C MOLDED CASE CIRCUIT BREAKER 600V 250A,1250...2500 A,250 A,20 kA 250 V DC-100 kA 240 V AC-65 kA 480 V AC-25 kA 600 V AC,250 V DC-600 V AC,250 A,250 V DC-600 V AC,3-Pole,J-Frame,Line Lug - Load Lug,Powerpact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
- Brochure URL - 11003_35R1PTDFMVK20N68.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_86e26fd7091d91eac4712e605cbef2835e4eb44b75b1f59c013fd6082b480e4e.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=JJL36250C_2D+Bottom+View.dwg(Computer~Aided [CAD|BIM] Model URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=JJL36250C_3D.stp(Computer~Aided [CAD|BIM] Model URL)
- Line Drawing URL(Line Drawing URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_YV3EWLGDB1KPRFOZ.pdf(Service Manual URL)
- Service Manual URL - 11003_Z7TW5GLP40EVI8H2.pdf(Service Manual URL)
- Spec Sheet URL - 11003_JOQ0VZBM86391TYR.pdf(Spec Sheet URL)
- Tech Bulletin URL - files?p_enDocType=Data+Bulletin&p_File_Name=0600DB1604.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_BFDSCUWEA6K9QLRI.pdf(Tech Drawing URL)
- Tech Drawing URL - 11003_CKU5AF7YLZ9SWVGB.pdf(Tech Drawing URL)
- User Manual URL - 11003_KMJFTUEYA5HS02OZ.pdf(User Manual URL)
- Video - https://www.youtube.com/embed/0ifsiqiXvbg(Video)
- Video - https://www.youtube.com/embed/GHPCn0u1IUE(Video)
- Video - https://www.youtube.com/embed/VuQhshcKxko(Video)
- User Manual URL - 11003_X4QGCHKPU1SLW5TD.pdf(User Manual URL)
- Applications
- Features
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Common mounting holes, handle locations and trim dimensions across the range allow design standardization for PowerPact™ H and J frame circuit breakers |
| Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes |
| A wide range of field installable accessories allows customers to reduce inventory without sacrificing flexibility |
| Equipped with a unique snap-in terminal design that makes converting between busbar and lug options easy |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 20 kA at 250 VDC, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC interrupt rating |
