Square D™ PowerPact™ HJL26125 Type HJL Molded Case Circuit Breaker, 600 VAC/250 VDC, 125 A, 2 Poles
Molded Case Circuit Breakers
429244
MFG #: HJL26125
Square D™
3857.91000
/ ea
Square D HJL26125 MOLDED CASE CIRCUIT BREAKER 600V 125A,100 kA 240 V AC-65 kA 480 V AC-25 kA 600 V AC-20 kA 250 V DC,250 V DC-600 V AC,125 A,125 A,1700 A,900 A,2-Pole,250 V DC-600 V AC,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
- Brochure URL - 11003_35R1PTDFMVK20N68.pdf(Brochure URL)
- Catalog URL - IDW_DOCUMENT_86e26fd7091d91eac4712e605cbef2835e4eb44b75b1f59c013fd6082b480e4e.pdf(Catalog URL)
- Compliance Cert URL - Square_D_HDA260151_Compliance_Certificate.pdf(Compliance Cert URL)
- Computer~Aided [CAD|BIM] Model URL(Computer~Aided [CAD|BIM] Model URL)
- Install Instructions URL - Square_D_HDA260151_Instruction_Sheet.pdf(Install Instructions URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_OHXSF8E4N5AQMWR2.pdf(Service Manual URL)
- Spec Sheet URL - 11003_B53ZQ2A0RVJEO9F8.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_VRP57W264AQSK31L.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_E86TOXILPZ7BY3JV.zip(Tech Drawing URL)
- User Manual URL - 11003_E9IAMWVOKTCDJUNZ.pdf(User Manual URL)
- Video - https://www.youtube.com/embed/08co8m1vWjY(Video)
- Video - https://www.youtube.com/embed/0ifsiqiXvbg(Video)
- Applications
- Features
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
