Square D™ PowerPact™ HJL26070 Type HJL Molded Case Circuit Breaker, 600 VAC/250 VDC, 70 A, 2 Poles
Molded Case Circuit Breakers
429240
MFG #: HJL26070
Square D™
1581.95000
/ ea
Square D HJL26070 MOLDED CASE CIRCUIT BREAKER 600V 70A,100 kA 240 V AC-65 kA 480 V AC-25 kA 600 V AC-20 kA 250 V DC,250 V DC-600 V AC,1450 A,70 A,800 A,2-Pole,250 V DC-600 V AC,70 A,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
- Brochure URL - 11003_35R1PTDFMVK20N68.pdf(Brochure URL)
- Catalog URL - Square_D_JDA261502_Brochure.pdf(Catalog URL)
- Computer~Aided [CAD|BIM] Model URL - files?p_enDocType=CAD&p_File_Name=HJL26070_3D.stp(Computer~Aided [CAD|BIM] Model URL)
- Line Drawing URL(Line Drawing URL)
- Seller Home Page URL - us(Seller Home Page URL)
- Service Manual URL - 11003_OHXSF8E4N5AQMWR2.pdf(Service Manual URL)
- Spec Sheet URL - 11003_4380SQ72MCUH9KGV.pdf(Spec Sheet URL)
- Tech Bulletin URL - 11003_VRP57W264AQSK31L.pdf(Tech Bulletin URL)
- Tech Drawing URL - 11003_SUDT8VA93LEHYBWZ.pdf(Tech Drawing URL)
- User Manual URL - 11003_E9IAMWVOKTCDJUNZ.pdf(User Manual URL)
- Video - https://www.youtube.com/embed/0ifsiqiXvbg(Video)
- Video - https://www.youtube.com/embed/eoDTK_hod_s(Video)
- Applications
- Features
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
