Square D™ PowerPact™ HJL26040 Type HJL Molded Case Circuit Breaker, 600 VAC/250 VDC, 40 A, 2 Poles
Custom_Product_Images_Illustration
Square D™ PowerPact™ HJL26040 Type HJL Molded Case Circuit Breaker, 600 VAC/250 VDC, 40 A, 2 Poles
SKU429237
MFGR #HJL26040
Your Cost: $1,351.87/ea
List: Square D HJL26040 MOLDED CASE CIRCUIT BREAKER 600V 40A,2-Pole,25 kA 600 V AC-65 kA 480 V AC-100 kA 240 V AC-20 kA 250 V DC,250 V DC-600 V AC,250 V DC-600 V AC,40 A,40 A,400 A,850 A,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
Square D HJL26040 MOLDED CASE CIRCUIT BREAKER 600V 40A,2-Pole,25 kA 600 V AC-65 kA 480 V AC-100 kA 240 V AC-20 kA 250 V DC,250 V DC-600 V AC,250 V DC-600 V AC,40 A,40 A,400 A,850 A,J,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
Actuator Type Toggle Alternate Catalog Number HJL26040 Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HJL26040 Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE Connection Type Line/Load Lugs Country of Origin MX Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 3.9500 lb Gross Weight per Pack Metric 1.79 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01115 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423627&lang=en-us Mounting Type Unit Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable N Standard UL LISTED-CE-CSA-IEC Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 400 to 850 A Type Type HJL UNSPSC 39121601 UPC 11 78590170654 UPC 12 785901706540 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 40 A Interrupt Rating 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION UNIT MOUNT Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator Type | Toggle |
| Alternate Catalog Number | HJL26040 |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HJL26040 |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lugs |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.9500 lb |
| Gross Weight per Pack Metric | 1.79 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01115 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=423627&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | N |
| Standard | UL LISTED-CE-CSA-IEC |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 400 to 850 A |
| Type | Type HJL |
| UNSPSC | 39121601 |
| UPC 11 | 78590170654 |
| UPC 12 | 785901706540 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 40 A |
| Interrupt Rating | 100 kA at 240 VAC/65 kA at 480 VAC/25 kA at 600 VAC/20 kA at 250 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 VDC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 480 VAC, 25 kA at 600 VAC, 100 kA at 240 VAC, 20 kA at 250 VDC interrupt rating |
