Square D™
Square D™ PowerPact™ HGL36035 Type HGL Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 35 A, 3 Poles
Custom_Product_Images_Illustration
Square D™
Square D™ PowerPact™ HGL36035 Type HGL Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 35 A, 3 Poles
SKU429227
MFGR #HGL36035
Your Cost: $1,294.64/ea
List: Square D HGL36035 MOLDED CASE CIRCUIT BREAKER 600V 35A,20 kA 250 V DC-65 kA 240 V AC-18 kA 600 V AC-35 kA 480 V AC,250 V DC-600 V AC,250 V DC-600 V AC,3-Pole,35 A,35 A,400 A,850 A,G,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
Square D HGL36035 MOLDED CASE CIRCUIT BREAKER 600V 35A,20 kA 250 V DC-65 kA 240 V AC-18 kA 600 V AC-35 kA 480 V AC,250 V DC-600 V AC,250 V DC-600 V AC,3-Pole,35 A,35 A,400 A,850 A,G,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
Alternate Catalog Number HGL36035 ARRA Compliant N Buy American Compliant N Catalog Number HGL36035 Connection Type Line/Load Lugs Country of Origin US Currency USD Dimensions 6.4 in H x 4.12 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 4.2100 lb Gross Weight per Pack Metric 1.91 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 11.0740 in Height [Metric] 11.0740 cm Item Group 01115 Length 16.2560 in Length [Metric] 16.2560 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422741&lang=en-us Mounting Type Unit Number Of Poles 3 Phase 3 pH Returnable Y Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 400 to 850 A Type Type HGL UNSPSC 39121616 UPC 11 78590159873 UPC 12 785901598732 Warranty Description Contractual Warranty:18 months Width 10.4650 in Width [Metric] 10.4650 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 35 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 to 500 VDC UNIT MOUNT Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Alternate Catalog Number | HGL36035 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGL36035 |
| Connection Type | Line/Load Lugs |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 4.12 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 4.2100 lb |
| Gross Weight per Pack Metric | 1.91 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 11.0740 in |
| Height [Metric] | 11.0740 cm |
| Item Group | 01115 |
| Length | 16.2560 in |
| Length [Metric] | 16.2560 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422741&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 3 |
| Phase | 3 pH |
| Returnable | Y |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 400 to 850 A |
| Type | Type HGL |
| UNSPSC | 39121616 |
| UPC 11 | 78590159873 |
| UPC 12 | 785901598732 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 10.4650 in |
| Width [Metric] | 10.4650 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 35 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 to 500 VDC |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating |
