Square D™ PowerPact™ HGL26070C Type HGL Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 70 A, 2 Poles
Custom_Product_Images_Illustration
Square D™ PowerPact™ HGL26070C Type HGL Molded Case Circuit Breaker, 600 VAC/250 to 500 VDC, 70 A, 2 Poles
SKU608710
MFGR #HGL26070C
Your Cost: $1,981.07/ea
Square D HGL26070C MOLDED CASE CIRCUIT BREAKER 600V 70A,1450 A,70 A,800 A,18 kA 600 V AC-35 kA 480 V AC-20 kA 250 V DC-65 kA 240 V AC,250 V DC-600 V AC,2-Pole,250 V DC-600 V AC,70 A,G,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
Square D HGL26070C MOLDED CASE CIRCUIT BREAKER 600V 70A,1450 A,70 A,800 A,18 kA 600 V AC-35 kA 480 V AC-20 kA 250 V DC-65 kA 240 V AC,250 V DC-600 V AC,2-Pole,250 V DC-600 V AC,70 A,G,PowerPact,Provides overload and short circuit protection,UL Listed - CSA Certified - IEC Rated,circuit breaker,thermal-magnetic,unit mount
Alternate Catalog Number HGL26070C Application PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION ARRA Compliant N Buy American Compliant N Catalog Number HGL26070C Connection AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE Connection Type Line/Load Lugs Country of Origin US Currency USD Dimensions 6.4 in H x 2.74 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame H Frequency Rating 50/60 Hz Gross Weight Per Pack 3.0000 lb Gross Weight per Pack Metric 1.36 Gross Weight UOM Metric kg Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01115 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422649&lang=en-us Mounting Type Unit Number Of Poles 2 Operating Temperature 40 °C Phase 1 pH Returnable N Standard CE-CSA-IEC-UL LISTED Sub Brand POWERPACT Temperature Rating 104 °F Trip Range 800 to 1450 A Type Type HGL UNSPSC 39121601 UPC 11 78590158209 UPC 12 785901582090 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 14 to 3/0 AWG Al/Cu Stock Status NONSTOCK Brand Square D™ Manufacturer Schneider Electric Amperage Rating 70 A Interrupt Rating 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC Trip Type Thermal Magnetic Voltage Rating 600 VAC/250 to 500 VDC PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION UNIT MOUNT Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields Flexible and simple offer, with proven performance Direct access to energy metering and energy efficiency 100% continuous current rating 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | HGL26070C |
| Application | PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | HGL26070C |
| Connection | AWG 14...AWG 3/0 ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lugs |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 2.74 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | H |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 3.0000 lb |
| Gross Weight per Pack Metric | 1.36 |
| Gross Weight UOM Metric | kg |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01115 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=422649&lang=en-us |
| Mounting Type | Unit |
| Number Of Poles | 2 |
| Operating Temperature | 40 °C |
| Phase | 1 pH |
| Returnable | N |
| Standard | CE-CSA-IEC-UL LISTED |
| Sub Brand | POWERPACT |
| Temperature Rating | 104 °F |
| Trip Range | 800 to 1450 A |
| Type | Type HGL |
| UNSPSC | 39121601 |
| UPC 11 | 78590158209 |
| UPC 12 | 785901582090 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 14 to 3/0 AWG Al/Cu |
| Stock Status | NONSTOCK |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 70 A |
| Interrupt Rating | 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250 VDC/500 VDC |
| Trip Type | Thermal Magnetic |
| Voltage Rating | 600 VAC/250 to 500 VDC |
| PROVIDES OVERLOAD AND SHORT CIRCUIT PROTECTION |
| UNIT MOUNT |
| Easy to install, extremely versatile, a wide variety of terminal options include mechanical lugs, crimp lugs, power distribution lugs and lug shields |
| Flexible and simple offer, with proven performance |
| Direct access to energy metering and energy efficiency |
| 100% continuous current rating |
| 65 kA at 240 VAC, 35 kA at 480 VAC, 18 kA at 600 VAC, 20 kA at 500 VDC, 20 kA at 250 VDC interrupt rating |
