Square D™ MJA263002 Molded Case Circuit Breaker, 600 VAC, 300 A, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, 2 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
Custom_Product_Images_Illustration
Square D™ MJA263002 Molded Case Circuit Breaker, 600 VAC, 300 A, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, 2 Poles, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip
SKUPDW~6410771
MFGR #MJA263002
Price Not Available
Square D™ I-Line™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 300 A, 50/60 Hz, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 600 to 3000 A Trip, 2 Pole, 1, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Al/Cu Wire, Plug-In Mount, -22 to 158 deg F
Square D™ I-Line™ PowerPact™ Molded Case Circuit Breaker, 600 VAC, 300 A, 50/60 Hz, 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Interrupt, M Frame, Electronic Basic ET 1.0 LI/Non-Interchangeable Trip, 600 to 3000 A Trip, 2 Pole, 1, Manual Actuator, Line/Load Lug, 3/0 AWG to 500 kcmil Al/Cu Wire, Plug-In Mount, -22 to 158 deg F
Actuator Type Manual Alternate Catalog Number MJA263002 ARRA Compliant N Buy American Compliant N Catalog Number MJA263002 Connection AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD EU RoHS Indicator Y Frame M Frequency Rating 50/60 Gross Weight Per Pack 0.1270 lb Gross Weight per Pack Metric 12.70 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 25.4000 in Height [Metric] 25.4000 cm Item Group 01200 Length 45.2450 in Length [Metric] 45.2450 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430979&lang=en-us Mounting Type Plug-In Number Of Poles 2 Phase 1 Returnable Y Standard IEC-CSA-UL LISTED Temperature Rating -22 to 158 Trip Range 600 to 3000 Type CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590150767 UPC 12 785901507673 Warranty Description Contractual Warranty:18 months Width 29.8450 in Width [Metric] 29.8450 cm Wire Size 3/0 AWG to 500 kcmil Al/Cu Brand Square D™ Manufacturer Schneider Electric Amperage Rating 300 Interrupt Rating 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC Trip Type Electronic Basic ET 1.0 LI/Non-Interchangeable Voltage Rating 600 VAC PLUG-IN
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Actuator Type | Manual |
| Alternate Catalog Number | MJA263002 |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | MJA263002 |
| Connection | AWG 3/0...500 KCMIL ALUMINIUM/COPPER)3,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Frame | M |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 0.1270 lb |
| Gross Weight per Pack Metric | 12.70 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 25.4000 in |
| Height [Metric] | 25.4000 cm |
| Item Group | 01200 |
| Length | 45.2450 in |
| Length [Metric] | 45.2450 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=430979&lang=en-us |
| Mounting Type | Plug-In |
| Number Of Poles | 2 |
| Phase | 1 |
| Returnable | Y |
| Standard | IEC-CSA-UL LISTED |
| Temperature Rating | -22 to 158 |
| Trip Range | 600 to 3000 |
| Type | CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590150767 |
| UPC 12 | 785901507673 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 29.8450 in |
| Width [Metric] | 29.8450 cm |
| Wire Size | 3/0 AWG to 500 kcmil Al/Cu |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 300 |
| Interrupt Rating | 100 kA at 240 VAC, 65 kA at 480 VAC, 25 kA at 600 VAC |
| Trip Type | Electronic Basic ET 1.0 LI/Non-Interchangeable |
| Voltage Rating | 600 VAC |
| PLUG-IN |
