Square D™
Square D™ M9F53301 Multi 9™ C60N Curve D Miniature Circuit Breaker, 240/415/440 VAC, 1 A, 10 kA Interrupt, 3 Poles, Thermal Magnetic Trip
Square D™
Square D™ M9F53301 Multi 9™ C60N Curve D Miniature Circuit Breaker, 240/415/440 VAC, 1 A, 10 kA Interrupt, 3 Poles, Thermal Magnetic Trip
SKUPDW~13031757
MFGR #M9F53301
Your Cost: $261.31/ea
List: Schneider Electric Square D™ Miniature Circuit Breaker, Curve D, Series: Multi 9™ C60N, 240/415/440 VAC, 1 A, 50/60 Hz Frequency, 10 kA Interrupt, Thermal Magnetic Trip, 3 Poles, Toggle Actuator, Ring Tongue Connection, IP20/IP40 Enclosure, Clip-On/DIN Rail Mounting, -30 to 70 deg C, 54 mm W x 72 mm D x 127 mm H Dimensions, Gray
Schneider Electric Square D™ Miniature Circuit Breaker, Curve D, Series: Multi 9™ C60N, 240/415/440 VAC, 1 A, 50/60 Hz Frequency, 10 kA Interrupt, Thermal Magnetic Trip, 3 Poles, Toggle Actuator, Ring Tongue Connection, IP20/IP40 Enclosure, Clip-On/DIN Rail Mounting, -30 to 70 deg C, 54 mm W x 72 mm D x 127 mm H Dimensions, Gray
Actuator Toggle Alternate Catalog Number M9F53301 Application Distribution ARRA Compliant N Buy American Compliant N Catalog Number M9F53301 Connection Ring terminal top or bottom) Country of Origin US Currency USD EU RoHS Indicator Y Gross Volume Per Pack 37.50 Gross Volume per Pack Metric 614.51 Gross Volume UOM CI Gross Volume UOM Metric cm3 Gross Weight Per Pack 4.6000 lb Gross Weight per Pack Metric 460.00 Gross Weight UOM Metric g Harmonization Tariff Schedule Code 8536200040 Height 7.5000 in Height [Metric] 7.5000 cm Item Group 00949 Length 12.7000 in Length [Metric] 12.7000 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=446710634&lang=en-us Number Of Poles 3 Returnable Y Standard EN/IEC 60947-2;GB 14048.2;UL 489;CSA C22.2 No 5;IEC;CCC;CSA;UL Sub Brand Multi9 C60;C60BPR Substitute Product Catalog Number M9A26929 Type Miniature circuit-breaker UNSPSC 39121603 UPC 11 78590113577 UPC 12 785901135777 Width 5.4000 in Width [Metric] 5.4000 cm Brand Square D™ Manufacturer Schneider Electric Trip Type Thermal-magnetic Voltage Rating 240 V AC 50/60 Hz;415 V AC 50/60 Hz;440 V AC 50/60 Hz Distribution ON/OFF indication
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | Toggle |
| Alternate Catalog Number | M9F53301 |
| Application | Distribution |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | M9F53301 |
| Connection | Ring terminal top or bottom) |
| Country of Origin | US |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Volume Per Pack | 37.50 |
| Gross Volume per Pack Metric | 614.51 |
| Gross Volume UOM | CI |
| Gross Volume UOM Metric | cm3 |
| Gross Weight Per Pack | 4.6000 lb |
| Gross Weight per Pack Metric | 460.00 |
| Gross Weight UOM Metric | g |
| Harmonization Tariff Schedule Code | 8536200040 |
| Height | 7.5000 in |
| Height [Metric] | 7.5000 cm |
| Item Group | 00949 |
| Length | 12.7000 in |
| Length [Metric] | 12.7000 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=446710634&lang=en-us |
| Number Of Poles | 3 |
| Returnable | Y |
| Standard | EN/IEC 60947-2;GB 14048.2;UL 489;CSA C22.2 No 5;IEC;CCC;CSA;UL |
| Sub Brand | Multi9 C60;C60BPR |
| Substitute Product Catalog Number | M9A26929 |
| Type | Miniature circuit-breaker |
| UNSPSC | 39121603 |
| UPC 11 | 78590113577 |
| UPC 12 | 785901135777 |
| Width | 5.4000 in |
| Width [Metric] | 5.4000 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 240 V AC 50/60 Hz;415 V AC 50/60 Hz;440 V AC 50/60 Hz |
| Distribution |
| ON/OFF indication |
