Square D™ LDA36400CU33X Standard Molded Case Circuit Breaker, 600 VAC, 400 A, 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC Interrupt, 3 Poles, Electronic Micrologic LSI Trip
Custom_Product_Images_Illustration
Square D™ LDA36400CU33X Standard Molded Case Circuit Breaker, 600 VAC, 400 A, 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC Interrupt, 3 Poles, Electronic Micrologic LSI Trip
SKUPDW~11735649
MFGR #LDA36400CU33X
Your Cost: $4,146.60/ea
List: Schneider Electric I-Line™ PowerPact™ Molded Case Circuit Breaker, Standard, 600 VAC, 400 A, 50/60 Hz Frequency, 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC Interrupt, L Frame Frame, Electronic Micrologic LSI Trip, 3 Pole, 3 ph, Line/Load Lug Connection, (2) 2/0 AWG to 500 kcmil Al/Cu Wire, NEMA 12 Enclosure, 122 deg F, 14.7 in H x 5.94 in W x 6.61 in D Dimensions
Schneider Electric I-Line™ PowerPact™ Molded Case Circuit Breaker, Standard, 600 VAC, 400 A, 50/60 Hz Frequency, 25 kA at 240 VAC/18 kA at 480 VAC/14 kA at 600 VAC Interrupt, L Frame Frame, Electronic Micrologic LSI Trip, 3 Pole, 3 ph, Line/Load Lug Connection, (2) 2/0 AWG to 500 kcmil Al/Cu Wire, NEMA 12 Enclosure, 122 deg F, 14.7 in H x 5.94 in W x 6.61 in D Dimensions
Actuator Toggle Alternate Catalog Number LDA36400CU33X Application Distribution;HACR rated ARRA Compliant N Buy American Compliant N Catalog Number LDA36400CU33X Connection AWG 2/0...500 KCMIL ALUMINIUM/COPPER)2,I-LINE CONNECTION LINE-LUGS LOAD Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 14.7 in H x 5.94 in W x 6.61 in D Enclosure Type NEMA 12 EU RoHS Indicator Y Frame D Frequency Rating 50/60 Hz Gross Weight Per Pack 0.0771 lb Gross Weight per Pack Metric 7.71 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 22.2250 in Height [Metric] 22.2250 cm Item Group 01118 Length 49.5300 in Length [Metric] 49.5300 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=402918394&lang=en-us Number Of Poles 3 Phase 3 Returnable Y Standard NMX-UL LISTED-CCC-CE-CSA Sub Brand PowerPact L;L-Frame Temperature Rating 122 Trip Range 400 A Type CIRCUIT BREAKER,CURRENT LIMITER UNSPSC 39121616 UPC 11 78590160950 UPC 12 785901609506 Warranty Description Contractual Warranty:18 months Width 27.3050 in Width [Metric] 27.3050 cm Wire Size (2) 2/0 AWG to 500 kcmil Al/Cu Brand Square D™ Manufacturer Schneider Electric Amperage Rating 400 A Interrupt Rating 18 KA AT 480 V AC-25 KA AT 240 V AC-14 KA AT 600 V AC,600 V AC Trip Type Electronic, standard, Micrologic 3.3 S, LSI Voltage Rating 600 VAC Distribution;HACR rated I-LINE
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Actuator | Toggle |
| Alternate Catalog Number | LDA36400CU33X |
| Application | Distribution;HACR rated |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LDA36400CU33X |
| Connection | AWG 2/0...500 KCMIL ALUMINIUM/COPPER)2,I-LINE CONNECTION LINE-LUGS LOAD |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 14.7 in H x 5.94 in W x 6.61 in D |
| Enclosure Type | NEMA 12 |
| EU RoHS Indicator | Y |
| Frame | D |
| Frequency Rating | 50/60 Hz |
| Gross Weight Per Pack | 0.0771 lb |
| Gross Weight per Pack Metric | 7.71 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 22.2250 in |
| Height [Metric] | 22.2250 cm |
| Item Group | 01118 |
| Length | 49.5300 in |
| Length [Metric] | 49.5300 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=402918394&lang=en-us |
| Number Of Poles | 3 |
| Phase | 3 |
| Returnable | Y |
| Standard | NMX-UL LISTED-CCC-CE-CSA |
| Sub Brand | PowerPact L;L-Frame |
| Temperature Rating | 122 |
| Trip Range | 400 A |
| Type | CIRCUIT BREAKER,CURRENT LIMITER |
| UNSPSC | 39121616 |
| UPC 11 | 78590160950 |
| UPC 12 | 785901609506 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 27.3050 in |
| Width [Metric] | 27.3050 cm |
| Wire Size | (2) 2/0 AWG to 500 kcmil Al/Cu |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 400 A |
| Interrupt Rating | 18 KA AT 480 V AC-25 KA AT 240 V AC-14 KA AT 600 V AC,600 V AC |
| Trip Type | Electronic, standard, Micrologic 3.3 S, LSI |
| Voltage Rating | 600 VAC |
| Distribution;HACR rated |
| I-LINE |
