Square D™ LAL362501027 Adjustable Standard Interrupt Molded Case Circuit Breaker With 24 VDC Shunt Trip, 600 VAC/250 VDC, 250 A, 42 kA at 240 VAC/30 kA at 480 VAC/22 kA at 600 VAC/10 kA at 125/250 VDC Interrupt, 3 Poles, Thermal Magnetic Trip
Custom_Product_Images_Illustration
Square D™ LAL362501027 Adjustable Standard Interrupt Molded Case Circuit Breaker With 24 VDC Shunt Trip, 600 VAC/250 VDC, 250 A, 42 kA at 240 VAC/30 kA at 480 VAC/22 kA at 600 VAC/10 kA at 125/250 VDC Interrupt, 3 Poles, Thermal Magnetic Trip
SKUPDW~11083832
MFGR #LAL362501027
Your Cost: $4,029.37/ea
List: Square D™ Molded Case Circuit Breaker, Adjustable Standard Interrupt, 600 VAC/250 VDC, 250 A, 50/60 Hz, 42 kA at 240 VAC/30 kA at 480 VAC/22 kA at 600 VAC/10 kA at 125/250 VDC Interrupt, LA Series Frame, Thermal Magnetic Trip, 1250 to 2500 A Trip, 3 Pole, 3, Line/Load Lug, (1) 1 AWG to 600 kcmil/(2)1 AWG to 250 kcmil Al/Cu Wire, NEMA 1/3R/12/4/4X/5, Unit Mount, 104 deg F, 11 in H x 6 in W x 5.84 in D
Square D™ Molded Case Circuit Breaker, Adjustable Standard Interrupt, 600 VAC/250 VDC, 250 A, 50/60 Hz, 42 kA at 240 VAC/30 kA at 480 VAC/22 kA at 600 VAC/10 kA at 125/250 VDC Interrupt, LA Series Frame, Thermal Magnetic Trip, 1250 to 2500 A Trip, 3 Pole, 3, Line/Load Lug, (1) 1 AWG to 600 kcmil/(2)1 AWG to 250 kcmil Al/Cu Wire, NEMA 1/3R/12/4/4X/5, Unit Mount, 104 deg F, 11 in H x 6 in W x 5.84 in D
Alternate Catalog Number LAL362501027 Application Construction, Commercial Buildings, Oil, Gas, Industrial Buildings, Water Wastewater and Data Center Applications ARRA Compliant N Buy American Compliant N Catalog Number LAL362501027 Connection Lugs load;lugs line Country of Origin MX Currency USD EU RoHS Indicator Y Gross Weight Per Pack 16.7800 lb Gross Weight per Pack Metric 7.61 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 8.2677 in Height [Metric] 21.4330 cm Item Group 00935 Length 16.9291 in Length [Metric] 43.4980 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=428159&lang=en-us Number Of Poles 3 Returnable N Standard UL LISTED-IEC-CSA Trip Range 1250 A,250 A,2500 A Type CIRCUIT BREAKER UNSPSC 39121601 UPC 11 78590197894 UPC 12 785901978947 Warranty Description Contractual Warranty:18 months Width 11.0236 in Width [Metric] 28.2580 cm Brand Square D™ Manufacturer Schneider Electric Amperage Rating 250 A Interrupt Rating 250 V DC-600 V AC,42 KA AT 240 V AC-30 KA AT 480 V AC-22 KA AT 600 V AC-10 KA AT 125 V DC-10 KA AT 250 V DC Trip Type Thermal-magnetic Voltage Rating 600 V AC-250 V DC Construction, Commercial Buildings, Oil, Gas, Industrial Buildings, Water Wastewater and Data Center Applications UNIT MOUNT Common accessories and auxiliaries with other PowerPact frames Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes A wide range of field installable accessories allow customers to reduce inventory without sacrificing flexibility Broad offering of operating mechanisms and ratings specifically designed to be used as the main panel disconnect for control panel applications IEC style rotary operating handles Equipped with a unique terminal design that makes converting between busbar and lug options easy Easy to install, extremely versatile, a wide variety of terminal options
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | LAL362501027 |
| Application | Construction, Commercial Buildings, Oil, Gas, Industrial Buildings, Water Wastewater and Data Center Applications |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | LAL362501027 |
| Connection | Lugs load;lugs line |
| Country of Origin | MX |
| Currency | USD |
| EU RoHS Indicator | Y |
| Gross Weight Per Pack | 16.7800 lb |
| Gross Weight per Pack Metric | 7.61 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 8.2677 in |
| Height [Metric] | 21.4330 cm |
| Item Group | 00935 |
| Length | 16.9291 in |
| Length [Metric] | 43.4980 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=428159&lang=en-us |
| Number Of Poles | 3 |
| Returnable | N |
| Standard | UL LISTED-IEC-CSA |
| Trip Range | 1250 A,250 A,2500 A |
| Type | CIRCUIT BREAKER |
| UNSPSC | 39121601 |
| UPC 11 | 78590197894 |
| UPC 12 | 785901978947 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 11.0236 in |
| Width [Metric] | 28.2580 cm |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 250 A |
| Interrupt Rating | 250 V DC-600 V AC,42 KA AT 240 V AC-30 KA AT 480 V AC-22 KA AT 600 V AC-10 KA AT 125 V DC-10 KA AT 250 V DC |
| Trip Type | Thermal-magnetic |
| Voltage Rating | 600 V AC-250 V DC |
| Construction, Commercial Buildings, Oil, Gas, Industrial Buildings, Water Wastewater and Data Center Applications |
| UNIT MOUNT |
| Common accessories and auxiliaries with other PowerPact frames |
| Common accessories across the range of PowerPact™ molded case circuit breakers allow users to make late specification changes |
| A wide range of field installable accessories allow customers to reduce inventory without sacrificing flexibility |
| Broad offering of operating mechanisms and ratings specifically designed to be used as the main panel disconnect for control panel applications |
| IEC style rotary operating handles |
| Equipped with a unique terminal design that makes converting between busbar and lug options easy |
| Easy to install, extremely versatile, a wide variety of terminal options |
