Square D™ JGL36225T Molded Case Circuit Breaker, 600 VAC, 225 A, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC Interrupt, 3 Poles, Thermal/Magnetic Trip
Custom_Product_Images_Illustration
Square D™ JGL36225T Molded Case Circuit Breaker, 600 VAC, 225 A, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC Interrupt, 3 Poles, Thermal/Magnetic Trip
SKUPDW~11729612
MFGR #JGL36225T
Your Cost: $4,887.47/ea
List: Schneider Electric PowerPact™ Molded Case Circuit Breaker, 600 VAC, 225 A, 50/60 Hz Frequency, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC Interrupt, J Frame Frame, Thermal/Magnetic Trip, 1125 to 2250 A Trip, 3 Pole, 3 ph, Line/Load Lug Connection, 3/0 AWG to 350 kcmil Wire, NEMA AB1 Enclosure, Surface Mounting, 104 deg F, 6.4 in H x 4.12 in W x 4.36 in D Dimensions
Schneider Electric PowerPact™ Molded Case Circuit Breaker, 600 VAC, 225 A, 50/60 Hz Frequency, 65 kA at 240 VAC/35 kA at 480 VAC/18 kA at 600 VAC/20 kA at 250/500 VDC Interrupt, J Frame Frame, Thermal/Magnetic Trip, 1125 to 2250 A Trip, 3 Pole, 3 ph, Line/Load Lug Connection, 3/0 AWG to 350 kcmil Wire, NEMA AB1 Enclosure, Surface Mounting, 104 deg F, 6.4 in H x 4.12 in W x 4.36 in D Dimensions
Alternate Catalog Number JGL36225T Application DISTRIBUTION ARRA Compliant N Buy American Compliant N Catalog Number JGL36225T Connection AWG 3/0...350 KCMIL ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE Connection Type Line/Load Lug Country of Origin US Currency USD Dimensions 6.4 in H x 4.12 in W x 4.36 in D Enclosure Type NEMA AB1 EU RoHS Indicator Y Frame G Frequency Rating 50/60 Gross Weight Per Pack 4.5000 lb Gross Weight per Pack Metric 2.04 Gross Weight UOM Metric kg Harmonization Tariff Schedule Code 8536200020 Height 13.0180 in Height [Metric] 13.0180 cm Item Group 01115 Length 21.4330 in Length [Metric] 21.4330 cm Material Composition Declaration https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425693&lang=en-us Mounting Type Surface Number Of Poles 3 Operating Temperature 40 A°C Phase 3 Returnable Y Standard CSA-UL LISTED-IEC-CE-CCC Temperature Rating 104 Trip Range 1125 A,225 A,2250 A Type Circuit Breaker UNSPSC 39121601 UPC 11 78590177123 UPC 12 785901771234 Warranty Description Contractual Warranty:18 months Width 18.4150 in Width [Metric] 18.4150 cm Wire Size 3/0 AWG to 350 kcmil Brand Square D™ Manufacturer Schneider Electric Amperage Rating 225 A Interrupt Rating 20 KA 250 V DC-65 KA 240 V AC-35 KA 480 V AC-18 KA 600 V AC-20 KA 500 V DC,500 V DC-600 V AC Trip Type THERMAL-MAGNETIC Voltage Rating 500 V DC-600 V AC Distribution TRIP UNIT FIELD INSTALLABLE
content loaded
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Applications
- Features
- Substitute Products
| Alternate Catalog Number | JGL36225T |
| Application | DISTRIBUTION |
| ARRA Compliant | N |
| Buy American Compliant | N |
| Catalog Number | JGL36225T |
| Connection | AWG 3/0...350 KCMIL ALUMINIUM/COPPER,LUGS LOAD-LUGS LINE |
| Connection Type | Line/Load Lug |
| Country of Origin | US |
| Currency | USD |
| Dimensions | 6.4 in H x 4.12 in W x 4.36 in D |
| Enclosure Type | NEMA AB1 |
| EU RoHS Indicator | Y |
| Frame | G |
| Frequency Rating | 50/60 |
| Gross Weight Per Pack | 4.5000 lb |
| Gross Weight per Pack Metric | 2.04 |
| Gross Weight UOM Metric | kg |
| Harmonization Tariff Schedule Code | 8536200020 |
| Height | 13.0180 in |
| Height [Metric] | 13.0180 cm |
| Item Group | 01115 |
| Length | 21.4330 in |
| Length [Metric] | 21.4330 cm |
| Material Composition Declaration | https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=425693&lang=en-us |
| Mounting Type | Surface |
| Number Of Poles | 3 |
| Operating Temperature | 40 A°C |
| Phase | 3 |
| Returnable | Y |
| Standard | CSA-UL LISTED-IEC-CE-CCC |
| Temperature Rating | 104 |
| Trip Range | 1125 A,225 A,2250 A |
| Type | Circuit Breaker |
| UNSPSC | 39121601 |
| UPC 11 | 78590177123 |
| UPC 12 | 785901771234 |
| Warranty Description | Contractual Warranty:18 months |
| Width | 18.4150 in |
| Width [Metric] | 18.4150 cm |
| Wire Size | 3/0 AWG to 350 kcmil |
| Brand | Square D™ |
| Manufacturer | Schneider Electric |
| Amperage Rating | 225 A |
| Interrupt Rating | 20 KA 250 V DC-65 KA 240 V AC-35 KA 480 V AC-18 KA 600 V AC-20 KA 500 V DC,500 V DC-600 V AC |
| Trip Type | THERMAL-MAGNETIC |
| Voltage Rating | 500 V DC-600 V AC |
| Distribution |
| TRIP UNIT FIELD INSTALLABLE |
